Parts/Service for ZIPS360NHSS
Uploaded: Nov. 21, 2025, 7:16 p.m.
Manual Publish Date: 2016-08-01
Warranty Information
GE offers a two-year limited warranty on parts and labor for manufacturing defects.
The refrigerator features electronic controls with a digital display for setting temperatures. The door alarm notifies if a door is left open for too long. Sabbath Mode disables features like lights and the icemaker. The water filter should be replaced when the status light turns red or ice quality diminishes.
Troubleshooting and error codes
| Freezer Display | Fresh Food Display | Diagnostics | Results | Comments |
|---|---|---|---|---|
| 0 | 1 | Showroom Mode | Enters showroom mode. | FF doors must be closed and reopened to start showroom mode. |
| 0 | 2 | Communication check between HMI and main control board. | 'P' on FZ display if okay. 'F' on FZ display means problem is found. | |
| 0 | 6 | HMI self test | All LED's and numeric segments will illuminate. | |
| 0 | 7 | Control and sensor system self-test. | Checks each thermistor and displays 'P' for pass and 'F' fail. | See Note 1 below. |
| 1 | 0 | Damper Test | Damper will open, pause briefly, then close. | |
| 1 | 2 | 100% Run Time | Sealed system on 100% of the time. Times out after 1 hour. | Cannot be entered if refrigerator is set to off. |
| 1 | 3 | Pre-chill Test | Starts pre-chill mode. Unit returns to normal on its own. | Cannot be entered if refrigerator is set to off. |
| 1 | 4 | Defrost Test | Toggles the defrost cycle. See Note 2 below. | Must press again to turn heaters off. Cannot be entered if refrigerator is set to off. See Note 2 below. |
| 1 | 5 | Main Control Reset | Causes a system reset. | |
| 1 | 6 | Exit Diagnostic Mode | Causes a HMI board reset. | |
| 1 | 7 | Degree C/F | Changes temperature display from F to C. |
