Getting Started

  • Inserting and Removing the Battery: Open the cover, insert the battery correctly, and close the cover. To remove, open the cover and release the lock lever.
  • Charging the Battery: Connect the AC adapter to the camera and a wall outlet. The status LED indicates charging.
  • Using an AC Power Adapter: Use to prevent automatic power-off during file transfer.
  • Inserting and Removing an SD Card: Open the cover, insert the card correctly (printed arrow facing the camera), and close the cover. To remove, open the cover and press the card edge.
  • Setting the Date and Time: Navigate through the Setup menu, select "Custom", then "Date/Time", and adjust the values.
  • Choosing the Display Language: In the Setup menu, select "Custom", then "Language", and choose from the available OSD languages.
  • Formatting an SD Memory Card: In the Setup menu, select "Format" and then "Execute". This erases all data.
  • Setting Image Resolution and Quality: In the "Capture" tab of the Photography menu, select "Size" and "Quality" to adjust resolution and compression.

Photography Mode

  • Auto Mode: The camera automatically sets exposure. Use the optical viewfinder or LCD monitor to compose shots.
  • Using the Digital Zoom: Activate digital zoom in the "Function" menu. Press and hold the zoom button to expand the image.
  • Setting the Flash: Toggle the flash button to select the desired flash mode, which varies by photography and scene mode.
  • Setting the Focus: Use the multi-selector button to choose focus settings.

Troubleshooting and error codes

Color State During power off During photography During connection to a PC
Green On - Ready for shot. System ready.
On Battery charging in progress. When the image is not in focus. Accessing files in progress.
Red Off The completion of battery charge. - -
Flashing - Flash charging in progress. Accessing files in progress.
