Manual for WTVC GAS DRYER
Uploaded: Nov. 21, 2025, 8:20 p.m.
3 OPERATION
3.1 Controls
Rotate the knob to the desired drying program and push the Start/Pause button. There are option buttons for delicate fabrics and saving energy. Dryer status is shown in LED's at the left of the display.
The LED indicators vary by model, showing status such as Ready In, Drying, Damp Dry, Regular Dry, Wrinkle Block/Finished, and Lint Filter.
Troubleshooting and error codes
| Problem | Possible Causes | Suggested Repairs |
|---|---|---|
| Dryer won't run | Power not on or has been disconnected. Door switch misaligned & doesn't get activated by door pin. Door pin broken, so door switch doesn't get activated. Control module failed. Door switch or wire harness failed. |
Reconnect and turn on power. Tighten screw (where door pin engages door switch) to realign front shield with door. Do not overtighten screw. Replace entire door. Check control module output voltages. Replace module if faulty. Check door switch & wire harness resistances. Replace faulty part. |
| Burner won't work | Motor overheated. Broken belt switch tripped. Motor control or motor failed. Lint screen hi-limit (thermal cutout) tripped. Gas valve failed. Heater hi-limit (thermal cutout) tripped. Wire harness failed. |
Wait for motor to cool down and thermal protector to reset. Reset broken belt switch. Check motor control voltage & motor resistance. Replace faulty part. Clean lint screen and clean lint and other debris from front shield, then replace hi-limit. Also check exhaust duct length & # of elbows. Check voltages to and resistances of parts. Replace faulty parts. Correct what caused overheating, then reset hi-limit. Run resistance or continuity checks to track down broken wire or connector. Replace failed wire harness. |
| Motor won't work | Motor overheated. Broken belt switch tripped. Motor control or motor failed. Lint screen hi-limit (thermal cutout) tripped. Wire harness failed. |
Wait for motor to cool down and thermal protector to reset. Reset broken belt switch. Check motor control voltage & motor resistance. Replace faulty part. Clean lint screen and clean lint and other debris from front shield, then replace hi-limit. Also check exhaust duct length & # of elbows. Run resistance or continuity checks to track down broken wire or connector. Replace failed wire harness. |
