Manual for HDW100WCT

Manual for HDW100WCT

Brand: Haier

Category: Dishwashers

Document Type: Manual

Language: EN

Uploaded: Nov. 21, 2025, 6:26 p.m.

  • Safety First: Always read safety instructions before use. Keep children supervised.
  • Loading: Remove large food particles. Load lower rack with pots/pans, upper rack with delicate items.
  • Detergent & Rinse Aid: Use specified dishwasher detergent. Refill rinse aid dispenser as needed.
  • Starting a Cycle: Ensure power and water are on. Load dishes, add detergent, press POWER, select cycle, and the wash begins.
  • End of Cycle: A buzzer sounds, and the END light turns on. Turn off the appliance, water, and wait before unloading.
  • Maintenance: Clean filter assembly and spray arms regularly.

Troubleshooting and error codes

Problems Solutions
Appliance does not start up
  • Fault with fuse in mains electricity supply.
  • Plug not inserted in wall socket.
  • Appliance door not closed properly.
  • Knob set to "RESET".
  • Water tap not turned on.
  • Blocked strainer in water intake hose.
Alarm sounds in a series of 2 beeps, pause, 2 beeps, pause...
  • Water is turned on and hose is connected properly.
  • Water supply to house is on and has sufficient pressure.
  • Water supply hose is not crimped or bent.
  • Filter for water supply hose is not clogged.
  • Drain hose is not too low.
Alarm sounds in a series of 3 beeps, pause, 3 beeps, pause...
  • Drain hose is not crimped or bent.
  • Drain hose is not too high.
Alarm sounds in a series of 4 beeps, pause, 4 beeps, pause... Temperature sensor failed. Call Authorised Service Center.
Alarm sounds in a series of 5 beeps, pause, 5 beeps, pause... Flood switch activated. Call Authorised Service Centre.
Alarm sounds in a series of 6 beeps, pause, 6 beeps, pause... Drain hose is too low.
Alarm sounds in a series of 7 beeps, pause, 7 beeps, pause... (END indicator on) Door is not properly closed.
Lower spray arm rotates with difficulty
  • Spray arm blocked by small items or food remains.
Lid in detergent compartment cannot be closed
  • Compartment overfilled.
  • Mechanism clogged with detergent remnants.
Remnants of detergent stuck inside dispenser Compartment was damp when filled. Ensure it's dry before adding detergent.
Water remains inside appliance after programme has ended
  • Blockage or kink in drainage hose.
  • Pump jammed.
  • Filters blocked.
  • Programme still running. Wait for it to end.
Unusual amount of foam
  • Washing up liquid used instead of rinse aid.
  • Remove spilled rinse aid.
Appliance stops suddenly while washing
  • Electricity supply cut off.
  • Water supply interrupted.
Knocking sound while washing Spray arm knocking against dishes.
Rattling sound while washing Crockery not stacked properly.
Knocking sound from inlet valves Normal; caused by pipe installation. No remedy.
Remnants of food stuck to dishes
  • Improper loading.
  • Too many items.
  • Items touching.
  • Insufficient detergent.
  • Wrong wash programme.
  • Obstructed spray arm.
  • Blocked spray arm nozzles.
  • Blocked or incorrectly fitted filters.
  • Waste-water pump jammed.
Plastic items are discoloured
  • Insufficient detergent.
  • Detergent lacks bleaching properties. Use one with a bleaching agent.
White stains on crockery, milky appearance on glasses
  • Insufficient detergent.
  • Rinse-aid setting too low.
  • No salt added (if water is hard).
  • Water softener setting too low.
  • Consider using detergent with phosphates.
Dishes, cutlery, etc. have not been dried
  • Programme without drying function selected.
  • Rinse-aid setting too low.
  • Items removed too soon.
Glasses have a dull appearance Rinse-aid setting too low.
Tea stains or lipstick not completely removed
  • Detergent lacks bleaching effect.
  • Washing temperature too low.
Traces of rust on cutlery Cutlery not sufficiently rustproof.
Glasses become clouded/discoloured, coating cannot be wiped off
  • Unsuitable detergent used.
  • Glasses not dishwasher-proof.
Smears on glasses/cutlery, metallic appearance Rinse-aid setting too high.
