Manual for HDW13GI / HDW14G2 HDW15G2P / HDW15G3

Manual for HDW13GI / HDW14G2 HDW15G2P / HDW15G3

Brand: Haier

Category: Dishwashers

Document Type: Manual

Language: EN

Uploaded: Nov. 21, 2025, 8:28 p.m.

Daily Use

Load the Baskets:

  • Ensure delicate glasses and porcelain are dishwasher-proof.
  • Do not use items made of wood, horn, aluminium, pewter, or copper.
  • Avoid items that absorb water (sponges, cloths).
  • Only use dishwasher-safe items.
  • Remove food residue and soften burned food before washing.
  • Place hollow items with the opening down; deep hollows at a slant.
  • Mix cutlery to prevent bonding. Ensure a gap between items.
  • Prevent glasses from touching.
  • Place small items in the cutlery basket.
  • Put light items in the upper basket, ensuring they don't move.
  • Check spray arms can move freely before starting.
  • Jingling noises indicate dishes may not be firmly positioned.
  • Place heavily soiled items in the bottom basket for better results.

Start a Programme:

  1. Close the door and open the water tap.
  2. Press the ON/OFF button.
  3. Select the programme and check the display for run-time.
  4. Optionally, select a start delay.
  5. Press START/PAUSE to begin or activate the delay start.
  6. The appliance remembers the last used programme.

Interrupting a Programme: Press START/PAUSE. The display shows 'P' flashing. Press START/PAUSE or open/close door to resume.

End of Programme: Display shows 0:00. Appliance switches off or goes to standby after 2 minutes. Open door carefully (hot steam). Close water tap. Remove dishes, starting with the lower basket. Leave door slightly ajar to aid drying.

Troubleshooting and error codes

ProblemPossible causePossible solution
The programme does not start.Appliance door is open.Close the appliance door.
Delay start is set.Refer to displayed time.
Mains plug is not connected in the mains socket.Connect the mains plug.
Fuse in the house circuit is damaged.Replace the fuse.
Rinse Aid Indicator is lighted.Rinse aid dispenser is empty.Refill Rinse aid till full.
Refill of rinse aid was not confirmed.Press and hold the START/ PAUSE button for 1 sec after each refill.
Acoustic alarm, display shows ALARMCODE E10 The appliance does not fill with water.Water tap is closed.• Open the water tap. Note: Whenever „Error 10“ is solved switch off the appliance and restart the programm.
Water inlet hose has a kink or a bend.Make sure that the position of the hose is correct.
In case of aqua-stop system: water protection is triggered; the marker (C) is red.The hose must be replaced.
Filter in the water inlet hose is clogged.Clean the filter at the inlet hose connections at tap and the rear of the appliance.
Water inlet is clogged.Check water flow from tap.
Water pressure is too low.Contact your local water authority.
Acoustic alarm, display shows ALARMCODE 620 The appliance does not drain sufficientlyFilters are clogged• Scoop out as much water as possible. • Clean filters. • Continue programme by pressing the START/PAUSE button.
the drainage is blocked• Scoop out as much water as possible. • Make sure that drain water-connection and piping is correct and not blocked. • Continue programme by pressing the START/PAUSE button.
Acoustic alarm, display shows ALARMCODE 830 Leak: The drain pump runs permanently!Anti-flood device is on: • There are water leakages in the appliance. • The water inlet valve is open and blocked. • The drainage is blocked.1 Close the water tap. 2 Disconnect appliance from power supply. 3 Contact Service.
All other Alarmcodes:Note Alarmcode2. Contact Service ; refer to CUSTOMER SERVICE
The dishes are not clean.Filters are clogged.Clean the filters.
Filters are not correctly assembled and installed.Make sure that the filters are correctly assembled and installed.
Spray arms are clogged.Remove remaining food remnants with a thin pointed object.
Programme was not applicable for the type of load and food remnants.Make sure that the programme is applicable for the type of load and food remnants.
Incorrect position of the items in the baskets.Water could not wash all items.Make sure that the position of the items in the baskets is correct and that the water can easily wash all items.
Spray arms could not turn freely.Make sure that the position of the items in the baskets is correct and does not cause the blockage of the spray arms.
No detergent or insufficient quality of detergent in the detergent dispenser.Make sure that you add the correct quantity detergent in the dispenser before you start a programme
The wash cycle was interrupted by a long break.Do not open the door or cut power supply during the wash cycle.
Whitish streaks, stains or bluish layers on glasses and dishes.Released quantity of rinse aid is too much.Decrease the released quan- tity of rinse aid. Refer to section DIFFERENT SETTINGS FOR RINSE AID.
Quantity of detergent was too much.Make sure that you add the correct quantity of detergent in the dispenser before you start a programme.
Combi detergent tablets used with a short programme might not fully dissolve.Select a longer programme when using combi detergent tablets.
Dry water drop stains on glasses and dishes.Rinse aid dosage is too low..Increase the released quantity of rinse aid. Refer to section DIFFERENT SETTINGS FOR RINSE AID.
The dishes are wet.Quality of rinse aid or Multitab.Cleaning product too old; change the product.
• Programme had no drying phase. • Programme had a low temperature drying phase.Open the door slightly and leave it ajar (about 100 mm) to help the drying process.
The dishes are wet and matt.Rinse aid dispenser is empty.Refill rinse aid into the dispender and reset the rinse aid indicator.
Quality of rinse aid or Multitab.Cleaning product too old; change the product.
