Brand: Haier
Category: Dryers
Document Type: Manual
Language: EN
Manual for HD90-A2959
Uploaded: Nov. 21, 2025, 7:24 p.m.
Warranty Information
Check the Warranty Card supplied with the product for warranty information.
- Preparation: Ensure the appliance is properly connected, water tank is empty and filters are clean. Prepare laundry by sorting, emptying pockets, closing zippers and buttons, and unfolding large items.
- Operation: Select a program using the knob, set functions like temperature, dry level, and delay. Press Start/Pause to begin. The dryer stops automatically when the cycle is complete.
- End of Cycle: Remove laundry promptly. Switch off and unplug the dryer. Empty the water tank and clean the lint and condenser filters.
- Using the Dryer Rack: For items not suitable for tumble drying, use the dryer rack by placing it in the drum as instructed.
Troubleshooting and error codes
| Code | Cause | Solution |
|---|---|---|
| F2 | Drain pump error. | Contact the customer service. |
| F32 | The condenser thermal sensor is open-circuited or short-circuited. | Contact the customer service. |
| F33 | ||
| F4 | Temperature of the laundry in the drum does not change. | Contact the customer service. |
| FC2 | Communication failure between PCB and display. | Contact the customer service. |
| LO | Temperature is too low. | Use the dryer when air temperature is higher than 5 °C. |
