Manual for HDHP80AW1
Uploaded: Nov. 21, 2025, 6:53 p.m.
Warranty Information
2-year Manufacturer's Warranty covering parts and labour for servicing within the country of purchase.
Daily Use: Ensure the appliance is not operated by persons with reduced capabilities without supervision. Do not operate with wet hands or bare feet. Avoid placing wet clothing on top. Ensure lint filters are cleaned before every load. Ambient temperature should be between 5°C and 35°C. Keep the area around the dryer free of dust and lint. Only dry textiles washed in water. Do not overload. Remove flammable items from pockets. Do not place heavy objects or heat sources on top. Do not touch the rear wall and drum during operation as they are hot. Do not operate with a damaged or missing lint filter.
Do not dry: Items soiled with cooking oil, acetone, alcohol, petrol, kerosene, spot removers, turpentine, waxes, or wax removers. Foam rubber, shower caps, waterproof textiles, rubber-backed articles, clothes/pillows with foam rubber pads. Do not drink condensed water. Note the cool down phase at the end of the cycle; garments may still feel hot.
Maintenance: Clean lint and condenser filters regularly. Disconnect from power before cleaning. Do not use water spray or steam. Do not use industrial chemicals. Replace damaged cords only with manufacturer-approved parts. Do not attempt to repair yourself.
Troubleshooting and error codes
| PROBLEM | POSSIBLE CAUSES | WHAT TO DO |
|---|---|---|
| Small amount of water in the drum at end of cycle | Water tank needs to be emptied. | Refer to 'Emptying the water tank'. |
| Environmental conditions may be affecting dryer operation. | If conditions are particularly hot, humid or cold, it is possible vaporised water may re-condense in the drum or on the inside of the door. | |
| Noises | Dryer is overloaded. | Remove some items from the dryer. |
| Dryer has a fault. | Continuous beeping or a musical series of beeps with a message displayed on the display. Refer to 'Fault codes'. | |
| Dryer Has not been levelled properly. | Adjust the adjustable foot under the dryer. Refer to 'Levelling the dryer'. | |
| Dryer makes unfamiliar noises. | At the start of the cycle the dryer may make some unfamiliar noises when the compressor turns on. This is normal. | |
| Vibration | Dryer is not installed on a stable surface. | Ensure the dryer is installed on a flat, stable surface. |
| Dryer is not level. | Ensure the dryer is correctly levelled. | |
| Creasing | Dryer is overloaded. | Remove some items from the dryer. |
| Cycle selection not appropriate for the load. | Choose appropriate cycle. Refer to 'Dry Cycles'. | |
| Dryer is overloaded. | Remove some items from the dryer. | |
| Dry Level selected too high for load type. | Try selecting a lower Dry Level. | |
| Dye transfer | White/light and coloured items not separated before drying. | Remember to separate white/light and coloured items before placing them in the dryer. Refer to 'Sorting' for tips to prevent dye transfer. |
| Wet items left sitting in the dryer for long periods of time before drying. | Refer to 'Sorting' for tips to prevent dye transfer. | |
| Linting | Lint filter not cleaned or replaced. | Ensure the lint filter is cleaned after every cycle and replaced correctly. Refer to 'Cleaning the filters'. |
| Loads not sorted correctly. | Dry lint-giving items separately from lint receivers. Also, dry similar colours together, eg light coloured items with light coloured items, dark items with dark items. Refer to 'Sorting'. | |
| Clothes over dried. | Over drying clothes in the dryer can cause them to attract lint. Use an auto sensing cycle or ensure you check your load if using the time dry cycles to avoid over drying. | |
| Fabric damage | Instructions on care label not followed. | Follow the instructions on the care label of the items. |
| DRYNESS LEVEL selected not appropriate for the fabric type. | Ensure the DRYNESS LEVEL selected is appropriate for the fabric type. Refer to the items care label. | |
| Metal parts on the items or in the load. | Fasten zips and other clasps before placing items in the dryer. | |
| Items not separated or dried on an appropriate cycle for the fabric type. | Dry similar items together. Ensure an appropriate cycle is selected. Refer to 'Drying rack'. | |
| Items fell off the rack when using RACK DRY. | Ensure the rack is installed correctly (refer to 'Sorting', 'Drying rack') and only one or two garments are placed on the rack at a time. | |
| Used a TIME DRY cycle and did not monitor the dryness of clothes during the cycle. | Ensure that clothes are checked for dryness during the cycle when using the timed programmes to avoid over drying. | |
| Tangling | Loads not separated during loading. | Try separating out larger items from smaller items. |
| Items loaded into the dryer incorrectly. | Load items individually into the dryer. Do not place folded items in the dryer. | |
| Load size too large. | Try drying smaller load sizes. Some cycles have a lower maximum load size. Refer to 'Drying rack'. | |
| Delicate items not dried on RACK DRY. | Dry pantyhose, bras, stockings and any other delicate items prone to tangling on the RACK DRY cycle. | |
| Sheets and duvet/doona covers due to their size, are prone to tangling. | Dry sheets and duvet/doona covers separately from other laundry, apart from towels. Ensure duvet/doona covers are buttoned or fastened closed before drying. Try adding a knotted towel to sheets loads if you are experiencing a lot of tangling. |
