Warranty Information

Check the Warranty Card supplied with the product for warranty information.

Getting Started Quickly

1. Connect the appliance to a power supply (220V-240V~/50Hz).

2. Ensure the lint filter and condenser filter are clean and properly installed.

3. Prepare the laundry by sorting clothes, emptying pockets, and checking care labels.

4. Activate the dryer by pressing the Power button.

5. Select the required program using the Left and Right buttons, and set functions like Dry-level, Delay, and Anti-crease.

6. Press Start/Pause to begin the drying cycle.

Care and Cleaning

Regularly clean the lint filter after each dry cycle.

Clean the condenser filter after each dry cycle.

Clean the sensors approximately four times a year.

Wipe the outside of the dryer and control panel with a damp cloth.

Clean the drum with a damp cloth and detergent to remove film build-up.

Troubleshooting and error codes

PROBLEM POSSIBLE CAUSES WHAT TO DO
Small amount of water in the drum at end of cycle Drain hose is blocked Check whether the drain hose is blocked. Check the drain hose is still attached at the back of the machine, and is not kinked or squashed.
Environmental conditions may be affecting dryer operation. If conditions are particularly hot, humid or cold, it is possible vaporised water may re-condense in the drum or on the inside of the door
Noises Dryer is overloaded. Remove some items from the dryer.
Dryer has a fault. Continuous beeping or a musical series of beeps with a message displayed on the display. Refer to 'Fault codes'.
Vibration Dryer is not levelled properly. Adjust the adjustable foot under the dryer.Refer to 'Levelling the dryer'.
Dryer makes unfamiliar noises. At the start of the cycle the dryer may make some unfamiliar noises when the compressor turns on. This is normal.
Dryer is not installed on a stable surface. Ensure the dryer is installed on a flat, stable surface.
Dryer is not level. Ensure the dryer is correctly levelled.
Creasing Dryer is overloaded. Remove some items from the dryer.
Cycle selection not appropriate for the load. Choose appropriate cycle. Refer to 'Dry Cycles'
Dryer is overloaded. Remove some items from the dryer.
Dry Level selected too high for load type. Try selecting a lower Dry Level.
Dye transfer White/light and coloured items not separated before drying. Remember to separate white/light and coloured items before placing them in the dryer.
Wet items left sitting in the dryer for long periods of time before drying. Refer to 'Sorting' for tips to prevent dye transfer.
Linting Lint filter not cleaned or replaced. Ensure the lint filter is cleaned after every cycle and replaced correctly. Refer to 'Cleaning the filters'.
Loads not sorted correctly. Dry lint-giving items separately from lint receivers. Also, dry similar colours together, eg light coloured items with light coloured items, dark items with dark items. Refer to 'Sorting'.
Clothes over dried. Over drying clothes in the dryer can cause them to attract lint. Use an auto sensing cycle or ensure you check your load if using the time dry cycles to avoid over drying.
Fabric damage Instructions on care label not followed. Follow the instructions on the care label of the items.
DRYNESS LEVEL selected not appropriate for the fabric type. Ensure the DRYNESS LEVEL selected is appropriate for the fabric type. Refer to the items care label.
Metal parts on the items or in the load. Fasten zips and other clasps before placing items in the dryer.
Items not separated or dried on an appropriate cycle for the fabric type. Dry similar items together. Ensure an appropriate cycle is selected.
Used a TIME DRY cycle and did not monitor the dryness of clothes during the cycle. Ensure that clothes are checked for dryness during the cycle when using the timed programmes to avoid over drying.
Tangling Loads not separated during loading. Try separating out larger items from smaller items.
Items loaded into the dryer incorrectly. Load items individually into the dryer. Do not place folded items in the dryer.
Load size too large. Try drying smaller load sizes. Some cycles have a lower maximum load size. Refer to "Drying cycles".
Sheets and duvet/doona covers due to their size, are prone to tangling. Dry sheets and duvet/doona covers separately from other laundry, apart from towels. Ensure duvet/doona covers are buttoned or fastened closed before drying.Try adding a knotted towel to sheets loads if you are experiencing a lot of tangling.
