Warranty Information
None
- Power Up: Plug the dryer into a properly installed and grounded power outlet (220-240V~50Hz).
- Laundry Loading: Open the door, load spun-dry laundry, and loosen the load. Check clothing labels for drying suitability.
- Setting Drying Time: Use the program knob to select the desired drying program (Sensor Program, Timed Program, or Air Dry).
- Program Operation: Press the "START/PAUSE" button to begin. Pause by pressing it again.
- Program Completion: The dryer stops, and an indicator light blinks. Remove laundry promptly. An "anti-crease" cycle may activate if laundry is not removed.
- Turning Off: Turn the program knob to "OFF" and switch off the power at the wall. Clean the filter after each load.
Troubleshooting and error codes
| Problem | Possible Cause |
|---|---|
| The dryer does not start | Is the dryer plugged in? Is the power on? Is the door closed properly? Has a drying program been set? Has the Start/Pause button been pressed? |
| The drying result is not good | Was the correct drying program set? Is the filter screen clean? Did the amount of the loaded laundry exceed the rated load? Was the laundry spun dry before being loaded into the dryer? Did the laundry become twisted during drying? |
