Manual for HDY-M60

OPERATING INSTRUCTIONS

Attention:

1.Before operation, clean off any dust and dirt inside the drum of the dryer with a damp towel.

2.Clean off any debris on the lint filter and in the duct to increase the drying efficiency.

Turning on power

Before turning on the power of the dryer check whether the supply voltage is in accordance with the value indicated on the name plate.

Preparation of laundry load

The dryer can only dry laundry which has been spun dry. Do not put in laundry which is still dripping wet or has excess water.

Make sure all pockets are empty before placing laundry in the dryer. Remove all lighters and matches.

Pull up zippers, mend loosened fasteners and tie up ribbons to prevent the laundry from being entangled. If necessary, put small items in a laundry bag.

To achieve a better drying result ensure the clothes are separated before loading into the dryer.

Load to dry

Warning:

1. Avoid drying wool, silk and other delicate fabrics, they maybe damaged.

2. Do not exceed the recommended load limit. This could damage the dryer as well as the laundry.

1. Power up

Insert the power plug into an appropriate power outlet that is properly installed and grounded. Operating power supply: 220-240V~50Hz.

2. Laundry loading

Open the door and load the laundry into the drum of the dryer. For a more energy efficient and better drying result, make sure the load has been spun dried. Loosen the load when placing in the dryer.

Note: Check labels on clothing before placing them in the dryer. Some articles are not suitable for machine dry. High temperature may damage the fabric.

3.Setting drying time

Turn the timer knob to set an optimal drying time according to the fabric type and quantity. You can choose cool cycle or warm cycle according to your needs and then press the “Start” button to start the dryer.

Note: 1. Before you set the drying time, ensure your hands are dry. 2. Please close the door and press the “Start” button to restart the machine after adding laundry during the cycle.

4. Program completion

Warm air cycle: Before the drying time comes to end, the dryer will add cold air to cool the clothes. After the timer stops, the knob will point to OFF. Open the door to remove the laundry.

Cool air cycle: Throughout the cycle, the heater does not activate. The laundry is dried by cool air.

Note: 1.To avoid timer interruption, please do not turn the timer knob to the grey area of the program cycle. 2. Clothes should go through the cooling down/airing phase of the cycle. If for any reason the dryer is stopped before the cycle has fininshed, dry clothes should be removed immediately and not left in the dryer. Clothes should be spread out to cool and not left bunched eg. in a clothes basket. Before you open the door, please switch off the power supply.

5. Cleaning the filter

Please clean the filter after each load.
