Brand: Haier
Category: Washing Machines
Document Type: Manual
Language: EN
Manual for HW80-B14979
Uploaded: Nov. 21, 2025, 6:21 p.m.
Warranty Information
Refer to the Warranty Card supplied with the product for warranty information.
Power Supply: Connect the washing machine to a 220V-240V~/50Hz power supply.
Water Connection: Ensure water inlet is clean and clear. Turn on the tap.
Preparing Laundry: Sort clothes by fabric type and dirt level. Separate whites from colors. Empty pockets. Close zippers and fasteners. Use a wash bag for delicates.
Loading: Add laundry piece by piece, do not overload. Close the door carefully.
Selecting Detergent: Use machine wash approved detergent. Choose universal, color, delicate, or special detergent as needed.
Adding Detergent: Slide out the drawer, add detergent to the correct compartments, and push the drawer back.
Switching On: Touch the "Power" button.
Selecting Programme: Turn the program knob to choose the desired program.
Adding Options: Select additional functions like "Delay", "i-time", "Temp.", "Speed", "Extra Rinse", "Steam", or "Stain removal" using the function buttons.
Starting: Touch the "Start/Pause" button to begin the wash cycle.
Interrupting/Cancelling: Press "Start/Pause" to interrupt, or "Power" for 2 seconds to switch off and then drain to cancel.
After Washing: The display shows "END". Remove laundry promptly. Turn off water supply, unplug the power cord, and leave the door open.
Buzzer: Activate/deactivate the buzzer by touching "Delay" and "Temp." buttons simultaneously for 3 seconds.
Water Connection: Ensure water inlet is clean and clear. Turn on the tap.
Preparing Laundry: Sort clothes by fabric type and dirt level. Separate whites from colors. Empty pockets. Close zippers and fasteners. Use a wash bag for delicates.
Loading: Add laundry piece by piece, do not overload. Close the door carefully.
Selecting Detergent: Use machine wash approved detergent. Choose universal, color, delicate, or special detergent as needed.
Adding Detergent: Slide out the drawer, add detergent to the correct compartments, and push the drawer back.
Switching On: Touch the "Power" button.
Selecting Programme: Turn the program knob to choose the desired program.
Adding Options: Select additional functions like "Delay", "i-time", "Temp.", "Speed", "Extra Rinse", "Steam", or "Stain removal" using the function buttons.
Starting: Touch the "Start/Pause" button to begin the wash cycle.
Interrupting/Cancelling: Press "Start/Pause" to interrupt, or "Power" for 2 seconds to switch off and then drain to cancel.
After Washing: The display shows "END". Remove laundry promptly. Turn off water supply, unplug the power cord, and leave the door open.
Buzzer: Activate/deactivate the buzzer by touching "Delay" and "Temp." buttons simultaneously for 3 seconds.
Troubleshooting and error codes
| Problem | Cause | Solution |
|---|---|---|
| CLR FLTR | Drainage error, water is not fully drained within 6 minutes. | Clean pump filter. Check drain hose installation. |
| E2 | Lock - error. | Shut the door properly. |
| E4 | Water level not reached after 12 minutes. | Make sure that tap is fully opened and water pressure is normal. |
| E8 | Drain hose is self-syphoning. Water protective level - error. |
Check drain hose installation. Contact the After sales service. |
| F3 | Temperature sensor - error. | Contact the After sales service. |
| F4 | Heating error. | Contact the After sales service. |
| F7 | Motor - error. | Contact the After sales service. |
| FA | Water level sensor error. | Contact the After sales service. |
| FCO, FC1 or FC2 | Abnormal communication error. | Contact the After sales service. |
| Unb | Unbalanced load - error. | Check and balance laundry load in the drum. Reduce the load. |
| Washing machine fails to operate. | Programme is not yet started. Door is not properly closed. Machine has not been switched on. Power failure. Child lock is activated. |
Check programme and start it. Close the door properly. Switch the machine on. Check power supply. Deactivate child lock. |
| Washing machine will not be filled with water. | No water. Inlet hose is kinked. Inlet hose filter is blocked. Water pressure is less than 0.03 MPa. |
Check water tap. Check inlet hose. Unblock inlet hose filter. Check water pressure. |
| Machine is draining while being filled. | Door is not properly closed. Water supply failure. |
Close the door properly. Ensure the water supply. |
| Drainage failure. | Height of drain hose is below 80 cm. Drain hose end could reach into water. Drain hose is blocked. Pump filter is blocked. Drain hose end is higher than 100 cm above floor level. |
Make sure that drain hose is properly installed. Make sure the drain hose is not in water. Unblock drain hose. Clean pump filter. Make sure that drain hose is properly installed. |
| Strong vibration while spinning. | Not all transportation bolts have been removed. Appliance has no solid position. |
Remove all transportation bolts. Ensure solid ground and a ev-elled position. |
| Operation stops before completing wash cycle. | Machine load is not correct. | Check load weight and balance. |
| Operation stops for a period of time. | Water or electric failure. | Check power and water supply. |
| Excessive foam floats drum and/or detergent drawer. | Detergent is not a appropriate. Excessive use of detergent. |
Check detergent recommen-dations. Reduce amount of detergent. |
| Automatic adjustment of washing time. | Washing programme duration will be adjusted. | This is normal and doesn't af-fect functionality. |
| Spinning fails. | Unbalance of laundry. | Check machine load and laun-dry and run a spinning pro-gramme again. |
| Unsatisfactory washing result. | Degree of pollution does not agree with selected programme Detergent quantitiy was not suf-ficient. Maximum load has been excee-ded. Laundry was unevenly distribu-ted in the drum. |
Select an other programme. Choose the detergent acc. to the degree of pollution and acc. to manufacturer specifications. Reduce loading. Loose the laundry. |
| Washing powder residues are on the laundry. | Insoluble particles of detergent can remain as white spots on the laun-dry. | Perform extra rinse. Try to brush the points from the dry laundry. |
| Laundry has grey patches. | Caused by fats such as oils, creams or ointments. | Choose an other detergent. Pretreat the laundry with a spe-cial cleaner. |
