Manual for RAS-EH18RHLAE/RAC-EH18WHLAE, RAS-EH24RHLAE/RAC-EH24WHLAE

Indoor Unit Functions:

• Operation LED: Lights during operation. Flashes/dims during heating for preheating (2-3 mins) or defrosting (5-10 mins every hour).
• Frost Wash LED: Lights when Frost Wash function is active. Blinks after 42 hours of cumulative usage to suggest manual Frost Wash.
• Timer LED: Lights up when the timer is working.
• Temporary Switch: Used to start/stop when the remote controller is not working. Operation defaults to automatic mode.

Outdoor Unit Functions:

• Drain Pipe: Drains condensed water.
• Connecting Cord and Insulation Pipe for Piping.
• Air Inlet (Back, Left Side) & Air Outlet.
• Caution: During heating, drain or defrost water flows from the outdoor unit. Do not close the drain outlet in cold areas to prevent freezing.

General Operation Precautions:

• Operate within manufacturer specifications.
• Do not operate with wet hands.
• Ventilate when using burning equipment.
• Avoid directing cool air at household heating apparatus.
• Ensure outdoor mounting is stable.
• Do not splash water on the unit.
• Avoid aerosol sprays near the indoor unit.
• Switch off unit and circuit breaker before cleaning.
• Turn off the circuit breaker for long periods of non-operation.
• Do not climb on or place objects on the outdoor unit.
• Do not place water containers on the indoor unit.
• Do not place plants under the airflow.
• Avoid operating with doors/windows open in high humidity for extended periods.
• Ensure room heat load is within unit capacity.
• Appliance can be used by children 8+ with supervision.
