Warranty Information

Refer to the store where you purchased your equipment for any issues.

Powering ON/OFF

Connect the unit to the mains socket and switch ON/OFF to the ON position. Tap the unit's U/I button or the remote's & button to turn the unit on. Tap the same buttons to return to STANDBY mode. Switch OFF at the rear or unplug for complete power off.

Selecting Modes

Press the MODE button repeatedly to cycle through DAB, FM, CD, USB, CARD, BT LINK, and AUX modes.

Adjusting the Volume

Use the VOLUME +/- dial on the unit or the remote control. Press MUTE on the remote to silence sound temporarily.

Setting the Time and Date

In DAB or FM mode, press and hold ■/MENU. Navigate to , then . Adjust hours and minutes using ◄►►I buttons and confirm with SELECT/MONO/ST. Auto-update options and 12/24 hour format can also be set.

Daily Timer

Press and hold TIMER on the remote. Set On and Off times, desired mode (DAB, FM, CD, USB, CARD), and volume. An indicator will show when the timer is active. To cancel, repeatedly press TIMER until 'Timer Off' is displayed.

Sleep Timer

Press SLEEP to cycle through options (e.g., SLEEP 90, SLEEP 60, SLEEP OFF). The unit will turn off after the selected time.

Troubleshooting and error codes

Menu	Description
No power	Ensure the mains cable is connected securely at both ends. Make sure that the ON mode is selected.
The remote control does not function	Use the remote control near the unit. Point the remote control at the remote sensor on the unit. Replace the battery in the remote control with a new one. Remove any obstacles between the remote control and the unit.
The unit does not respond when pressing any buttons	The unit may freeze up during use. Switch the unit off and then on again at the mains socket to reset the unit.
CD The disc does not play	There is no disc inside the unit (“NO DISC” appears on the display). Insert the disc correctly with the label side facing up. Clean the disc. PAUSE mode may be activated, deactivate it. A non-valid disc has been inserted. Condensation may have formed inside the unit due to a sudden change in temperature. Wait about an hour for it to clear and try again.
Disc skips	Make sure the unit is on a secure spot. Vibrations or jarring can cause the disc to skip.
File from Media storage device does not play	Check the file format. This product only supports MP3 File formats.
Radio Desired station not found	Weak signal. Use the Manual Tune function. No DAB coverage in your area or poor reception. Adjust the position of the aerial.
USB & Memory Card Unable to insert USB device or memory Card.	Insert the USB device or memory card the other way round.
Cannot play some files from USB device or memory Card.	Some USB devices or memory cards may not be compatible with the unit. Only MP3 file formats are supported.
Bluetooth I cannot find "BT Speaker N" on my Bluetooth device.	Ensure the Bluetooth function is activated on your Bluetooth device.
