Warranty Information
Contact Hitachi Home Electronics for in-warranty service, operation, or technical assistance.
\n
Quick Index
\n- \n
- Charging the Battery.....12 \n
- Making a Basic Recording.....27 \n
- PlayBack.....27 \n
- Using Power Zoom.....35 \n
- Using Digital Zoom.....35 \n
- Using the Wireless Remote Control.....42 \n
- Dubbing from camcorder to VCR.....45 \n
Getting Started
\nThis section guides you through the initial preparation of the camcorder. It covers charging the battery, adjusting settings like the electronic viewfinder and hand strap, loading batteries, and inserting cassettes. It also explains how to check battery charge and use alternative power sources like the AC adapter/charger and car battery. You'll learn about using the linear time counter and setting the date and time.
\nBasic Techniques
\nLearn how to make a basic recording and playback your recordings on a TV.
\nAdvanced Techniques
\nExplore features like programmable editing, controlling your TV with the camcorder's remote, audio/video dubbing, recording TV programs, and attaching optional accessories like converter lenses and camera lights.
\nGeneral Maintenance
\nCovers cleaning the camcorder heads, lens, and viewfinder. It also provides periodic maintenance advice and troubleshooting tips for common issues like cassette loading problems, no picture, out-of-focus images, and battery conditions.
\nTroubleshooting and error codes
| Symptom | Check Point & Correction |
|---|---|
| INSERTING OR REMOVING THE CASSETTE: Cassette holder cannot be opened when you slide EJECT switch |
• Connect the power source • Load cassette in direction indicated by arrow on cassette • Cassette window must be toward outside. |
| INSERTING OR REMOVING THE CASSETTE: Cassette cannot be inserted into cassette compartment |
• Load cassette in direction indicated by arrow on cassette • Cassette window must be toward outside. |
| CAMERA RECORDING: Picture does not appear in the viewfinder or LCD monitor. |
• Remove the lens cap. • Slide the CAM/OFF/VIDEO switch to CAM. • Disconnect the AV input cable from the camcorder. |
| CAMERA RECORDING: The camcorder cannot go into the recording mode, even when the start/stop button is pressed. |
• Check the record-protect tab on the cassette. See page 19 for details. • Push the cassette holder embossed PUSH LOCK to close it. • Slide the CAM/OFF/VIDEO switch to CAM. |
| CAMERA RECORDING: Picture is out of focus. |
• Make sure that FOCUS does not appear in the viewfinder or LCD monitor. If it is displayed, press FOCUS Control buttons to erase it. |
| Auto-focus does not operate. | • Auto-Focus does not operate if a special-effects filter is attached or the objects shown on page 35 are being recorded. |
| The created title does not appear | • Insert the clock battery, then create a title. • Do not remove the clock battery after creating a title. |
| The LCD monitor does not turn on. | • It does not turn on when alkaline batteries are used to power the camcorder. Use another power supply. • The LCD monitor cannot be powered through the DC cord while alkaline batteries are left in the camcorder. First remove the batteries, and then connect the DC cord to power the camcorder. • When you are viewing the picture on the LCD monitor the DC camera light cannot be used. |
| The optional DC camera light cannot be used. | • When you are viewing the picture on the LCD monitor the DC camera light cannot be used. |
| RECORDING TV PROGRAMS OFF THE AIR: The camcorder cannot be set to the recording mode, even when the Start/Stop button on the camcorder is pressed |
• Check the record-protect tab on the cassette. See page 19 for details. • Set the CAM/OFF/VIDEO switch to CAM. • Connect the camcorder and TV or VCR. |
| PLAYBACK OF PRE-RECORDED CASSETTE: "PLAY" button cannot be engaged. |
• Set the CAM/OFF/VIDEO switch to VIDEO |
| PLAYBACK OF PRE-RECORDED CASSETTE: No picture appears on television screen when "PLAY" is pressed. . (TV is connected to the camcorder by using RF output adapter.) |
• Set the television to the camcorder channel (3 or 4) depending upon the selected channel in the RF channel select switch of RF output adapter. |
| PLAYBACK OF PRE-RECORDED CASSETTE: Interference on playback picture. (TV is connected to the camcorder by using output adapter.) |
• When you see the playback picture on your TV, RF adjust fine tuning knob on television set to obtain best picture |
| Picture bends at the top of the TV screen | • TV receiver is of older type. It needs to be modified to work properly with camcorder. • Tape is damaged. Try another cassette. • Color of your TV screen is too bright, too faint or change • TV set has VIR circuit. Turn it off during playback |
| Date search function does not operate | • Slide the CAM/OFF VIDEO switch to VIDEO. Insert the clock battery, set the date and time, and then start recording. • Do not remove the clock battery after recording. • Do not eject the recorded cassette. Leave it in the camcorder. |
| BATTERY CONDITION: The () indication in the electronic viewfinder flashes to indicate battery is discharged. |
• Try another battery or charge the battery. |
| BATTERY CONDITION: The battery level indicator ( ) appears differently on the LCD monitor and in the viewfinder. |
• This does not indicate a fault; it is because the power consumed by the LCD monitor and viewfinder is different. |
| NO OPERATION IS ACCEPTED: Power is turned on, but no button operations are accepted |
• Remove the power source and the date/title battery. And, after about one minute, the display in the viewfinder will be reset. Then set the information again. |
| NO OPERATION IS ACCEPTED: The camcorder does not operate when alkaline batteries are inserted. |
• Check that the polarities (+, -) of the batteries are correct. Insert six batteries. |
| TAPE DISPLAY: TAPE appears in the viewfinder |
• Have you moved the camcorder or cassette from a cold place to a warm place so that its temperature changed abruptly? • If the temperature has changed, remove the cassette and set the CAM/OFF/VIDEO switch to OFF, then wait for about one hour. • Remove the cassette and then try to reinsert: remove it several times. • If the indication is still shown in the viewfinder, use a cleaning tape to clean the heads and replace the cassette. |
