Warranty Information

Limited warranty for 1 year on parts (excluding battery) and 90 days on labor for defects.

  • Charging the Battery: Connect the AC adapter/charger to an outlet and plug the battery in until flush. The CHARGE light indicates charging status.
  • Connecting to a Television: Use the AV stereo output cable with S-VIDEO plug or the optional RF output adapter.
  • Basic Recording: Load a cassette, set the switch to CAM, and press the start/stop button to record.
  • Playback: Load a cassette, set the switch to VIDEO, and press PLAY.

Troubleshooting and error codes

Symptom Check Point & Correction
Cassette holder cannot be opened when you push EJECT button. * Connect the power source
Cassette cannot be inserted into cassette direction indicated compartment. * Load cassette in by arrow on cassette.
* Cassette window must be outside.
Picture does not appear in the viewfinder * Remove the lens cap.
* Slide the CAMERA/OFF/VIDEO switch to CAM.
* Disconnect the AV input cable from the camera/recorder.
The camera/recorder cannot go into the recording mode, even when the start/stop button is pressed. * Check the record-protect tab on the cassette. See page 22 for details.
* Push the cassette holder PUSH to close it.
* Slide the CAM/OFF/VIDEO switch to CAM.
Picture is out of focus. Make sure that FOCUS does not appear in the viewfinder.
.If it is displayed, press button to erase it.
* Auto-Focus does not operate if special-effects filter is the objects shown are being recorded.
"PLAY" button cannot be engaged. Check Point & Correction
Set the power switch to "VIDEO" position.
No picture appears on television screen when "PLAY” button is pressed. Set the television to the camera/recorder channel (3 or 4) depending upon the selected channel in the RF channel select switch of RF output adapter. (TV is connect to the camera/recorder by using RF output adapter.)
Interference on playback picture. When you see the playback picture on yourTV, adjust fine tuning knob on television set to obtain best picture.
Picture bends at the top of the TV screen. TV receiver is older type. It needs to be modified to work properly with camera/recorder.
Color of your TV screen is too bright, too faint or change. Tape is damaged, try another cassette.
TV set has VIR circuit. Turn off during playback.
The "�" indication in the electronic viewfinder Try another battery or charge the battery.
Power is not turned on an no button operations are accepted. Remove the power source, and after about one minute, push the reset switch gently using a toothpick, etc. until you feel a click. The display will be reset. Then set the information again.
