General Operation

This manual covers the operation of the HITACHI KP-DE500 and KP-E500 CCD Cameras. Before use, read this manual carefully and keep it for future reference. The cameras feature ultra-high sensitivity due to EM-CCD sensors, high color fidelity with RGB filters, and advanced digital signal processing.

Key Features:

• Sensitivity: Ultra-high sensitivity with EM-CCD technology for low-light performance.
• Image Quality: High color fidelity and vertical resolution.
• DSP: New digital signal processor for improved S/N ratio.
• Functions: Includes Auto Tracking White Balance (ATW), Digital Noise Reduction (DNR), Electric Shutter Speed, Sensitivity Enhance, Backlight Compensation (BLC), and Text Display (Character Generator).

Operating Considerations:

• Power Supply: Use the specified power source. Turn off power before connecting/disconnecting.
• Handling: Do not remove covers. Handle lenses carefully to avoid dust entry.
• Installation: Avoid direct sunlight, rain/snow, corrosive gases, extreme temperatures (-10 to 50°C), humidity, dust, vibration, or strong electromagnetic fields.
• Sunlight: Do not aim the camera lens at the sun to avoid vertical trailings and potential picture quality degradation.
• Continuous Use: For long-term operation, keep the ambient temperature below 40°C to prevent deterioration of internal parts.
• Cleaning: Use a blower or brush for dust removal. Wipe the case with a dry, soft cloth. Avoid harsh solvents.

CCD Phenomena:

Be aware of inherent phenomena like smear/blooming (blue belts from strong light), fixed pattern noise (high temperatures), moire (fine patterns), and burning (excessive intense light over time).
