Warranty Information

Warranty details not explicitly stated in this section, but implied as a standard offering.

Operation

Temperature control

This refrigerator controls its temperature automatically. Set the dial to "3" for normal use. Adjustments can be made for specific needs:

  • Freezer: Use higher settings (4-5) for quick ice making, frozen food preparation, or when the ambient temperature is high. Use lower settings (1-2) for storing neither frozen food nor ice cream.
  • Refrigerator: Use higher settings (4-5) for cooling food more coldly or quickly. Use lower settings (1-2) for normal use or when food is too cold.

Note: Setting to "Max" for extended periods may freeze food. Setting to "Min" may cause food temperature to rise.

Freezer

  • Ice making: Fill water to the "WATER LEVEL" and turn the lever clockwise to drop ice into the "Ice Bank".

Refrigerator

  • Chilled case: For keeping meat and fish fresh, but store in the freezer for longer preservation. Be cautious as items with high moisture content may freeze.
  • Egg pocket: Can hold up to 14 eggs.
  • Adjusting the shelves: Pull out shelves to adjust their position.
  • Crisper: Adjust the lever for humidity (left) or dryness (right).
  • "MINUS-ZERO" panel: Avoid striking the panel. Do not let food touch it directly to prevent freezing.

Troubleshooting and error codes

The refrigerator does not get cold at all.
  • Is the refrigerator plugged in properly?
  • Check the fuse box for blown fuse or tripped circuit breaker.
The refrigerator does not get cold enough.
  • Is the refrigerator placed in the direct sunlight?
  • Is the refrigerator placed near heat source?
  • Is the temperature control dial set to "MIN"?
Food in the refrigerator compartment freezes.
  • Do you place the high moisture food and vegetables at the inner part of the shelf nearby the cold air vent?
  • They will be frozen if being placed nearby the cold air vent.
Dew appears. Outside
  • When the high humidity outside and door gasket will have dew. Please wipe it up by dry cloth.
Dew appears. Inside
  • Please wipe it up with dry cloth and please check the details below.
  • Is the door closed firmly?
  • Is the door being opened and closed too frequently or opened for a long time?
  • Is it high humidity, is not it?
The inside is smelling.
  • Do you store odor food without wrapping it?
  • Make sure the refrigerator is installed firmly.
  • Is the refrigerator touching the wall?
Sound is noisy.
  • Did you too much make ice cups in the freezer room?
  • Condensation can occur when you leave the door open for along time then it frost forms on the wall.
  • Is the air vent blocked?
Frost forms on the wall of the freezer room
  • Condensation can occur when you leave the door open for along time then it frost forms on the wall.
  • Is the air vent blocked?
This is not out of order.
  • The refrigerator contains the dew prevention and heat radiation pipes.
  • Especially the back may be heated when starting up or if the door is frequently opened and closed.
  • The air duct of two compartment is connected. When close one of the door, another door may be opened by the wind pressure. This is a normal phenomenon.
  • The sounds like water flowing and boiling water are sound of the cooling liquid (refrigerant).
  • A creaking sound comes from the storage compartment. It is the sound caused by friction of the parts due to temperature change.
The surface of the refrigerator is hot.
  • The refrigerator contains the dew prevention and heat radiation pipes.
  • Especially the back may be heated when starting up or if the door is frequently opened and closed.
If a door is shut, other doors may open.
  • The air duct of two compartment is connected. When close one of the door, another door may be opened by the wind pressure. This is a normal phenomenon.
Does it have any abnormal sound?
  • The sounds like water flowing and boiling water are sound of the cooling liquid (refrigerant).
  • A creaking sound comes from the storage compartment. It is the sound caused by friction of the parts due to temperature change.
