Warranty Information
Refer to the manufacturer for specific warranty details.
User Tips
Honeywell Portable Air Conditioners are ideal for spot cooling. The unit is easy to move and offers a flexible air conditioning solution. The Auto Evaporation System automatically evaporates condensate, usually eliminating the need to empty the drainage tank. For optimal efficiency, keep doors and windows closed when using the air conditioner or dehumidifier. For fan-only mode, an open window can improve circulation.
Important: Place the unit upright for 1 hour before use to allow refrigerant to stabilize. The air outlet automatically opens when the unit is turned on and closes when turned off. Manually adjust the air vent for airflow direction. Ensure the unit is plugged into a properly grounded circuit and do not use an extension cord.
Modes
- COOL: Adjust fan speed and temperature (16°C - 32°C / 61°F - 89°F).
- DRY: Fan speed is preset to LOW. Exhaust hose can be disconnected for dehumidifier-only use.
- FAN: For air circulation without cooling.
- HEAT (on applicable models): Set temperature between 16°C - 32°C (61°F - 89°F). Requires draining from lower drain plug and venting exhaust hose outside.
- SLEEP: Modifies temperature settings gradually over a 10-hour period for enhanced comfort and energy saving. Can be deactivated by pressing any button.
Controls
Power Control: Turns the unit on/off. A red light indicates Standby Mode.
Fan Speed: High, Medium, Low settings.
Timer Control: Set auto turn-off or auto turn-on from 1 to 24 hours.
Temperature Control: Adjust thermostat settings. Display toggles between Celsius and Fahrenheit by pressing both + and - buttons simultaneously.
Water Full Light: Illuminates when the internal tank is 50% full and alarms when 100% full, requiring draining.
Note: After switching off, wait 3 minutes before restarting the compressor.
Troubleshooting and error codes
| PROBLEM | POSSIBLE CAUSE | SOLUTION |
|---|---|---|
| The air conditioning unit does not start | • No electricity. • Batteries in the remote control need to be replaced. • The power cord is not properly plugged in. • The safety LCDI plug has tripped (USA / Canada / Mexico only). |
• Check for power. • Change remote control batteries. • Remove and reconnect the power cord. • Reset the safety LCDI plug, if problem persists contact our customer support (USA / Canada / Mexico only). |
| Runs only a short while | • The thermostat temperature setting is too close to the room temperature. | • Lower the set temperature. |
| Runs but not cooling | • Air outlet is blocked. • There are tight bends in the air exhaust hose. • A door or window is open. • The air filter is dirty. • The exhaust hose is detached. • Temperature setting is too high. • Air outlet or intake is blocked. • Room exceeds recommended size. • Large size or number of windows are decreasing cooling effectiveness. |
• Make sure the exhaust hose is properly connected. • Connect exhaust hose as per instructions on page 4. • Make sure the window or door is closed. • Clean the air filter. • Reinstall exhaust hose properly (refer to Installation section). • Reduce temperature setting. • Remove blockage. • Move unit to smaller room. • Cover windows with curtains or blinds. |
| Will not run and WATER FULL indicator is on | • Excess water condensation inside the tank. | • Drain the water (refer to Water Condensation Drainage). |
| Heater* is not switching ON (This applies to Portable Air Conditioner models with built-in Heating* function only). | • Heating* function not activated yet. Temperature setting is too low. |
• Check that the Heating* function has been activated. Increase temperature setting. |
