Brand: Honeywell
Category: Scanner
Document Type: Manual
Language: EN
Manual for Xenon/Granit
Uploaded: Nov. 21, 2025, 8:47 p.m.
Warranty Information
Consult the website for warranty information and click Get Resources > Product Warranty.
This user guide provides installation and programming instructions for Xenon 1900 corded area-imaging scanners, Xenon 1902 cordless area-imaging scanners, Granit 1910i and 1980i corded industrial scanners, and Granit 1911i and 1981i cordless industrial scanners. It also includes product specifications, dimensions, warranty, and customer support information. Honeywell bar code scanners are factory programmed for the most common terminal and communications settings. Programming is accomplished by scanning the bar codes in this guide.
Troubleshooting and error codes
| Reset the Factory Defaults: All Application Work Groups | Factory Default Settings: All Application Groups | PAPDFT& | 70 |
| Reset the Custom Defaults: All Application Work Groups | Custom Default Settings: All Application Groups | PAPDFT | 71 |
| Replace a Linked Scanner | Override locked Scanner (Single Scanner) | BT_RPL1 | 45 |
| Reset Scanner | Reset Scanner | RESET_ | 52 |
| Base Charge Modes | Base Charge Off | BASCHG0 | 53 |
| *External or Interface Cable Power | BASCHG1 | 53 | |
| External Power Only | BASCHG2 | 54 | |
| Page Mode | *On | BEPPGE1 | 54 |
| Off | BEPPGE0 | 54 | |
| Page Pitch | Range 400 - 9000 Hz (*1000) | BEPPFQ#### | 54 |
| *Low (1000 Hz) | BEPPFQ1000 | 54 | |
| Medium (3250 Hz) | BEPPFQ3250 | 55 | |
| High (4200 Hz) (max 9000Hz) | BEPFQ24200 | 55 | |
| Beeper Pitch - Base Error | *Razz (250) (min 200Hz) | BASFQ2250 | 55 |
| Medium (3250) | BASFQ23250 | 55 | |
| High (4200) (max 9000Hz) | BASFQ24200 | 55 | |
| Number of Beeps - Base Error | *1 | BASERR3 | 55 |
| Range 1 - 9 | BASERR# | 55 | |
| Scanner Report | Scanner Report | RPTSCN | 56 |
| Scanner Address | Scanner Address | BT_LDA | 56 |
| Base or Access Point Address | Base Address | *:BASLDA | 56 |
| Scanner Modes | Charge Only Mode | *:BASLNK0 | 57 |
| *Charge and Link Mode | *:BASLNK1 | 57 | |
| Locked Link Mode | BASCON0,DNG1 | 58 | |
| *Open Link Mode | BASCON1,DNG1 | 58 | |
| Unlink Scanner | BT_RMV | 58 | |
| Override Locked Scanner | BT_RPL1 | 58 | |
| Out-of-Range Alarm | Base Alarm Duration (Range 1 - 3000 sec (*0)) | BASORD | 59 |
| Scanner Alarm Duration (Range 1 - 3000 sec (*0)) | BT_ORD | 59 | |
| Alarm Sound Type | Base Alarm Type | BASORW | 59 |
| Scanner Alarm Type | BT_ORW | 59 | |
| Scanner Power Time-Out Timer | Timer (0-7200 seconds) | BT_LPT0 | 60 |
| 200 Seconds | BT_LPT200 | 60 | |
| *400 Seconds | BT_LPT400 | 60 | |
| 900 Seconds | BT_LPT900 | 60 | |
| 3600 Seconds | BT_LPT3600 | 60 | |
| 7200 Seconds | BT_LPT7200 | 60 | |
| Flexible Power Management | *Full Power | BT_TXP100 | 61 |
| Medium Power | BT_TXP35 | 61 | |
| Medium Low Power | BT_TXP5 | 61 | |
| Low Power | BT_TXP1 | 61 | |
| Batch Mode | Automatic Batch Mode | BATENA1 | 62 |
| *Batch Mode Off | BATENA0 | 62 | |
| Inventory Batch Mode | BATENA2 | 62 | |
| Persistent Batch Mode | BATENA3 | 62 | |
| Batch Mode Beep | Off | BATBEP0 | 63 |
| *On | BATBEP1 | 63 | |
| Batch Mode Storage | *Flash Storage | BATNVS1 | 63 |
| RAM Storage | BATNVS0 | 63 |
