Manual for f150

Manual for f150

Brand: HP

Category: Digital Camera

Document Type: Manual

Language: EN

Uploaded: Nov. 21, 2025, 7:02 p.m.

Manual Publish Date: 2013-01-01

Warranty Information

HP shall not be liable for technical or editorial errors or omissions contained herein.

Charging the camera

  • Before first use, charge the battery using AC adapter or PC USB.
  • While charging the Status LED will flash. Upon completion, it will turn off.

Mode Selection

  • Press Power button to turn on camera.
  • Press Mode button to switch between the two camera modes (Video, Photo) and the two wireless modes (Direct, Cloud).

Two Camera Modes

  • Insert a micro memory SD card.
  • Video: Press the Mode button to select Video Mode. Press Record to capture video, press again to stop.
  • Photo: Press the Mode button to select Photo Mode. Press Record to take still photos.

Two Wireless Modes

  • Direct Mode - local: Connect your f150 to your mobile unit or PC directly for remote control, live view, managing albums, and camera & cloud setup.
  • Cloud Mode - Internet: Connect the f150 to a Cloud server via Access Point (AP) or mobile Hotspot for Internet live video streaming or monitoring.

Troubleshooting and error codes

Situation Solution
Camera will not turn on Battery power is low. Recharge the battery.
Camera is frozen Press Power button for 5 sec. to turn off. Press Power button twice to turn on.
Camera cannot record No SD card, card is not seated, or card is full. SD is not recognized. Format the SD card using HP Ucam or try another SD card.
Camera not found Turn on camera, switch to Direct Mode. Press "Refresh" on mobile or PC to scan again.
Forgot camera password Press both Mode and Record buttons for 4 sec. to reset the camera password, if used.
No live view on mobile Move camera closer to mobile device.
Flickering segments on live view TV system setting (50Hz/60Hz) is incorrect.
Cloud connection error AP or mobile Hotspot is not on.
No Cloud AP or Cloud AP SSID/Password is incorrect.
Camera is not in wireless area or, weak signal. Move camera closer to AP or mobile Hotspot.
No Cloud account, or account info incorrect.
No internet or Cloud server is not accessible.
Cloud service may be blocked by network firewall.
