Manual for UPS Management Module
Uploaded: Nov. 21, 2025, 8:24 p.m.
Manual Publish Date: 2010-01-01
Warranty Information
The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services.
The HP UPS Management Module allows monitoring, management, and control of power environments for up to five devices. It can be configured to send alert traps to SNMP management programs or used as a standalone system. Key features include monitoring UPS status, performing diagnostics, managing graceful shutdowns, prioritizing equipment shutdown, delaying restarts, scheduling shutdowns, sending email and broadcast notifications, issuing computer commands at power failure, displaying logs, supporting redundant UPS configurations, enhanced HP SIM integration, multi-language support, serial and network-attached server communications, customizable Events script, and simultaneous IPv4 and IPv6 support.
Troubleshooting and error codes
| SNMP trap code | SNMP trap message |
|---|---|
| 0 | General_Failure |
| 1 | Temperature_Bad |
| 2 | Awaiting_Power |
| 3 | Bypass_Bad |
| 4 | Charger_Failure |
| 5 | Fan Failure |
| 6 | Fuse_Failure |
| 7 | Input_Bad |
| 8 | Output_Bad |
| 9 | Output_Off |
| 10 | Overload |
| 11 | Shutdown_Imminent |
| 12 | Shutdown_Pending |
| 13 | System_Off |
| 14 | UPS_Shutdown |
| 15 | Bad_Battery |
| 16 | Low_Battery |
| 17 | Depleted_Battery |
| 18 | On_Bypass |
| 19 | On_Battery |
| 20 | General_UPS_Failure |
| 21 | Manual_Bypass_Switch_On |
| 22 | Site_Wiring_Fault |
| 23 | Manual_Load_Dumped |
| 24 | Battery_Disconnected |
| 25 | Bypass_Not_Available |
| 26 | Check Breaker |
| 27 | EPO_Initiated |
| 28 | UPS_Started_On_Battery |
| 29 | Loss_Of_Redundancy |
| 30 | Agent_Not_Connected |
| 31 | Loss_Of_Redundancy |
| 32 | Loss_Of_Redundant_Power |
| 33 | On_Boost |
| 34 | On_Buck |
