Startup:

  1. Switch on all connected equipment.
  2. Plug the power cord into the projector and a wall socket.
  3. Turn on the wall socket switch.
  4. Press the Power button on the remote or projector. The Power button flashes during warm-up and then turns solid.
  5. The projector searches for input signals, displaying the search status on screen. You can also use the 'Source' button to select your input signal.

Shutdown:

  1. Press the Power button. The Power button flashes, the lamp shuts down, and fans run for approximately 2 minutes to cool the projector.
  2. Disconnect the power cord. Do not unplug the power cord before the shutdown sequence is complete.

Source Selection:

  • Press the 'Source' button on the projector or remote control to cycle through input sources (VGA, Composite-video, S-Video). The selected source appears on screen for 3 seconds. A quick search can be done by pressing the key repeatedly.

Troubleshooting and error codes

Cause Remedy
The projector does not turn on. There is no power from the power cord.
Plug the power cord into the AC inlet on the projector, and plug the power cord into the power outlet. If the power outlet has a switch, make sure that it is switched on.
Attempting to turn the projector on again during the cooling process.
Wait until the cooling down process has completed.
No picture The video source is not turned on.
Turn the video source on.
The projector is not correctly connected to the input source device.
Check that the signal cable is connected correctly.
The input signal has not been correctly selected.
Select the correct input signal with the source button on the projector or remote control.
The lens cap is still attached to the lens.
Remove the lens cap.
Blurred image The projection lens is not correctly focused.
Adjust the focus of the lens using the focus ring.
The projector and the screen are not aligned properly.
Adjust the projection angle and direction as well as the height of the unit if necessary.
The lens cap is still attached to the lens.
Remove the lens cap.
Remote control does not work. The battery is out of power.
Replace the battery in the remote control with a new one.
There is an obstacle between the remote control and the projector.
Remove the obstacle.
You are too far away from the projector.
Stand within 6 meters (19.5 feet) of the projector.
For a PC connection, the USB cable is not connected.
To use the page up and page down functions, connect the USB cable between the PC and projector.
