Warranty Information
No specific warranty period is mentioned in the provided document excerpt.
The DPS Blade V100R001C50 is an outdoor and indoor wall-mounted power supply solution for wireless micro base stations. It integrates power supply, energy storage, distribution, monitoring, cooling, surge protection, and grounding. The manual details product overview, composition, installation and maintenance modes, configuration procedures, and descriptions. Key configuration steps include determining AC input voltage, power grid types, identifying high temperature areas, site proximity to the sea, selecting scenarios, input load power, power backup time, lithium battery models, calculating battery quantity, live-C app requirement, number of loads, communication cables, and installation mode. It also covers configuration rules for accessories, cables, terminals, and auxiliary material packages, along with spare parts and license configuration.
Troubleshooting and error codes
| Item | Troubleshooting Content | Possible Cause | Solution |
|---|---|---|---|
| Power supply failure | The PSU is not working. | The AC power input is not powered on. | Check the AC power input. |
| Power supply failure | The PSU is not working. | The PSU is faulty. | Replace the PSU. |
| Battery failure | The battery is not working. | The battery is not connected. | Check the battery connection. |
| Battery failure | The battery is not working. | The battery is faulty. | Replace the battery. |
| Communication failure | The communication between devices fails. | The communication cable is not connected. | Check the communication cable connection. |
| Communication failure | The communication between devices fails. | The communication module is faulty. | Replace the communication module. |
