Manual for HG8245H
Uploaded: Nov. 21, 2025, 6:40 p.m.
Manual Publish Date: 2013-05-20
The EchoLife ONT GPON Terminal HG8245H is an indoor optical network terminal for home users. It offers comprehensive triple play services (Internet, IPTV, VoIP), secure Wi-Fi access (802.11b/g/n), home network attached storage via USB, and robust gateway functions. It supports automatic provisioning and remote management. Key features include multiple LAN ports, POTS ports for voice, and a USB port for storage. The device provides high-speed data, voice, and video services through GPON technology.
Troubleshooting and error codes
| No. | PON | LOS | Description |
|---|---|---|---|
| 1 | Off | Off | The ONT is disabled by the OLT. |
| 2 | Blinks quickly (twice per second) | Off | The ONT is attempting to set up a connection to the OLT. |
| 3 | Always on | Off | The connection between the ONT and the OLT is set up. |
| 4 | Off | Blinks slowly (once two seconds) | The Rx optical power of the ONT is lower than the optical receiver sensitivity. The ONT is not connected to optical fibers or does not send optical signals. |
| 5 | Blinks quickly (twice per second) | Blinks quickly (twice per second) | The OLT detects that the device is a rogue ONT. |
| 6 | Blinks quickly (twice per second) | Blinks slowly (once two seconds) | The Rx optical power of the ONT does not within the range (-27 dBm to -8 dBm) of the Rx sensitivity. |
