Warranty Information
This product comes with an 8-year warranty from INSPIRE.
Installation:
- Mount the ceiling bracket securely.
- Attach the motor housing to the bracket.
- Install the fan blades.
- Connect the wiring according to local electrical codes.
- Install the remote control receiver.
Operation:
- Use the remote control to turn the fan on/off, adjust speed, set timers, and control the light (dimming and color temperature).
- Refer to the remote control diagrams for specific button functions.
- The "I Feel" function adjusts fan speed based on ambient temperature.
Maintenance:
- Always disconnect power before cleaning or maintenance.
- Clean with a dry cloth only.
Troubleshooting and error codes
| PROBLEM | PROBABLE CAUSE | SUGGESTED REMEDY |
|---|---|---|
| The fan does not start | • The fan is under protection. • The fuse or circuit breaker has tripped. • Loose wiring connections to the fan. • The speed controller is not in the correct position. | • Restart the fan after 10 seconds without power. • Check the fuses or circuit breakers of the main circuit and branch circuit. • Check the electrical connections between the cables and the fan. • Check the speed controller position. |
| The fan is noisy | • Top canopy touching the ceiling. • Fan blade screws are loose. • The fan is not securely fixed to the ceiling. • Incorrect speed controller. | • Lower the canopy to ensure a minimum gap of 3 mm between the blades and the ceiling. • Retighten all fan blade screws, but do not overtighten. • Retighten all screws of the support or hanging plate. • Change the controller. |
| Mechanical noise | • Fan blades are not horizontal relative to the ceiling. • Fan blade screws are loose. | Allow at least 8 hours for settling. • Measure the distance from the ceiling to the tips of the blades, then rotate the fan to check if all blades are at the same distance from the ceiling (adjustments can be made by applying slight upward or downward pressure on the blade holders). • Ensure all screws are tightly fastened. |
