Manual for RX-E100RSL
Uploaded: Nov. 21, 2025, 7:54 p.m.
Basic Operations:
- Turn On/Off: Press the POWER button (or AUDIO | for on) on the unit or remote control. The STANDBY lamp indicates power status.
- Select Source: Press the source selecting buttons (DVD, STB, VCR, TV, TAPE, FM/AM) on the unit or remote to choose the input.
- Adjust Volume: Use the MASTER VOLUME +/- buttons (or VOLUME +/- on remote) to increase or decrease volume.
- TV Direct: Press the TV DIRECT button to use the unit as an AV selector without turning it on.
- Muting: Press MUTING to temporarily silence all sound.
- Sleep Timer: Press SLEEP to set a shut-off time.
- Display Brightness: Press DIMMER to adjust screen illumination.
- Digital Input Terminals: Configure connections for digital sources.
- Analogue/Digital Input Mode: Select the input type for digital sources.
- Subwoofer Information: Set up subwoofer parameters.
- Speaker Settings: Configure sizes for DSP modes.
- Delay Time: Adjust center and rear speaker delay.
- Crossover Frequency: Set the crossover frequency for speakers.
- Dynamic Range Compression (D.R.C.): Adjust sound compression for quieter listening.
- Low Frequency Effect Attenuator (LFE): Reduce bass distortion.
- Auto Surround: Automatically activate surround modes with multichannel signals.
- TV Direct Mode: Set automatic TV Direct operation.
- Theatre Surround: Activate theatre surround sound for Dolby Surround sources.
- DAP Modes: Select from various Digital Audio Processing modes for stereo sources.
- Surround Modes: Activate Pro Logic, Dolby Digital, or DTS Digital Surround.
- Operate this unit and other JVC products using the remote.
- Learn to use 10-key functions for sound adjustments, tuner operations, and controlling other components.
- Refer to the chart for solutions to common problems like no power, no sound, or reception issues.
- Provides technical details on amplifier output, audio/video inputs/outputs, tuner performance, and general unit characteristics.
Troubleshooting and error codes
| PROBLEM | POSSIBLE CAUSE | SOLUTION |
|---|---|---|
| The power does not comes on. | The power cord is not plugged in. | Plug the power cord into an AC outlet. |
| No sound from speakers. | Speaker signal cables are not connected. | Check speaker wiring and reconnect if necessary. |
| An incorrect source is selected. | Select the correct source. | |
| Muting is activated. | Press MUTING to cancel the mute. | |
| An incorrect input mode (analogue or digital) is selected. | Select the correct input mode (analogue or digital). | |
| Connections are incorrect. | Check connections. | |
| Sound from one speaker only. | The balance is set to one extreme. | Adjust the balance properly (see page 20). |
| Continuous hiss or buzzing during FM reception. | Incoming signal is too weak. | Connect an outdoor FM antenna or contact your dealer. |
| The station is too far away. | Select a new station. | |
| An incorrect antenna is used. | Check with your dealer to be sure you have a correct antenna. | |
| Occasional cracking noise during FM reception. | Antennas are not connected properly. | Check connections. |
| Ignition noise from automobiles. | Move the antenna farther from automobile traffic. | |
| "OVERLOAD" starts flashing on the display. | Speakers are overloaded because of high volume. | 1. Press POWER on the front panel to turn off the unit. 2. Stop the playback source. 3. Turn on the unit again, and adjust the volume. |
| Speakers are overloaded because of short circuit of speaker terminals. | Press POWER on the front panel to turn off the unit, then check the speaker wiring. If "OVERLOAD" does not disappear, unplug the AC power cord, then plug it back again. If speaker wiring is not short-circuited, contact your dealer. |
|
| The STANDBY lamp lights up after turning on the power, but soon the unit turns off (into standby mode). | The unit is overloaded because of a high voltage. | Press POWER on the front panel to turn off the unit. After unplugging the power cord, consult your dealer. |
| Remote control does not operate as you intend. | The remote control is not ready for your intended operation. | Press SOUND or source selecting buttons first, then press the button you want to use. (See pages 40 and 41.) |
| Remote control does not work. | There is an obstruction hiding the remote sensor on the unit. | Remove the obstruction. |
| Batteries are weak. | Replace batteries. | |
| RDS/DVD MENU mode selector is set to the wrong position. | Set RDS/DVD MENU mode selector to the proper position. |
