Warranty Information

No warranty information found in the provided pages.

Basic DVD Operations

  1. Turn On the Power: Press STANDBY/ON / AUDIO button.
  2. Select the Source: Press DVD.
  3. Load a DVD: Press disc tray open/close button, then place DVD label-side up.
  4. Start Playback: Press /II.
  5. Adjust the Volume: Use VOLUME +/- buttons.
  6. Activate Surround or DSP Mode: Press DSP MODE button.
  7. Stop Playback: Press twice.

Basic VCD/CD Operations

  1. Turn On the Power: Press STANDBY/ON / AUDIO button.
  2. Select the Source: Press DVD.
  3. Load a VCD/CD: Press disc tray open/close button, then place disc label-side up.
  4. Start Playback: Press /II.
  5. Adjust the Volume: Use VOLUME +/- buttons.
  6. Activate DSP Mode: Press DSP MODE button.
  7. Stop Playback: Press twice.

Basic Tuner Operations

  1. Turn On the Power: Press STANDBY/ON / AUDIO button.
  2. Select the Band: Press FM/AM.
  3. Adjust the Volume: Use VOLUME +/- buttons.
  4. Tune into a Station: Use TUNING +/- buttons.

Other Basic Operations

  • Enjoying Sounds from the External Component: Select AUX as the source.
  • Turning Off the Power with the Timer: Press SLEEP button.

Troubleshooting and error codes

PROBLEM POSSIBLE CAUSE SOLUTION
Power does not come on. The power cord is not plugged in. Insert the plug into the socket.
The remote control does not work. • It is too far from the center unit, or is not facing the center unit.
• There is something obstructing the remote sensor.		 • Come close to the center unit.
• Avoid any obstacles.
No sound. • The VCR CONTROL button has been pressed.
• The battery is flat.
• The battery has been inserted the wrong way round (+/-).
• Sunlight is falling directly on the detector.		 • Press DVD or FM/AM to operate the system. (See page 54.)
• Replace the battery.
• Insert the battery correctly.
• Shade the remote control from direct sunlight.
Sound is emitted from only one speaker. • There is a short in the speaker cord.
• The audio cord is not connected properly.
• An incorrect source has been selected.		 • Reconnect the speaker cord.
• Connect the cord properly. (See page 8.)
• Select the correct source. (See pages 10 to 15.)
No video. • Muting is on.
• The disc is copy-protected CD.
• The speaker cord is not connected correctly.
• Left-right balance is incorrect.		 • Press MUTING to cancel muting.
• Replace the disc.
• Connect the cord properly. (See page 7.)
• Adjust balance. (See pages 20 to 24.)
A disc cannot be played. • The video cord is not connected properly.
• TV input selection is incorrect.
The system and disc region code numbers are incompatible.		 • Connect the cord properly. (See page 9.)
• Select the correct input.
• Replace the disc. (See page 25.)
"WRONG DISC FORMAT" appears on the TV screen. • The disc causes the parental (rating) error. • Enter password to change the parental (rating) level. (See page 53.)
Video and audio are distorted. • The CD-R/CD-RW does not contain any MP3 files.
• The disc is dirty.
• A VCR is connected between the center unit and the TV.		 • Replace the disc.
• Clean the disc.
• Connect the center unit and TV directly.
The edge is missing on the video image. • Initial setup (TV screen size) was incorrect. • Set TV screen size correctly. (See pages 51 and 52.)
Continuous static during FM broadcasts. The received signal is too weak. • Connect an external FM antenna (see page 5), or contact your dealer.
The system does not work correctly. • The station is too far away.
• The antenna is not connected correctly.
Lightning or electronic noise interferes with operation of the microcomputer.		 • Select another station.
• Check the connection. (See page 5.)
• Switch power off, and remove and re-insert the power plug in the socket.
The VCR cannot be operated using this remote control. • Immediately after beginning to heat the room, the unit was moved to a cold location causing condensation to form inside.
• The remote control is not set for VCR operations.
• The VCR is not a JVC's product.		 • Switch power off and leave the unit a few hours before switching power on again.
• Press VCR CONTROL to operate the VCR. (See page 54.)
• This remote control can operate a JVC's VCR whose remote control code is set to A code.
