Brand: JVC

Category: Audio System

Document Type: Manual

Language: EN

Uploaded: Nov. 21, 2025, 7:21 p.m.

Warranty Information

Retain information for future reference.

  • Powering On/Off: Press AUDIO / or STANDBY/ON on the front panel.
  • Selecting Source: Use the SOURCE button or press dedicated source buttons (DVD, FM/AM, AUX).
  • Adjusting Volume: Use the AUDIO VOL +/- buttons on the remote or the VOLUME control on the front panel.
  • Disc Operations: Load discs by pressing the tray open button, then press play. Use playback controls (play, pause, stop).
  • Sound Modes: Activate Surround (Dolby Pro Logic II, DTS, Dolby Digital) or DSP modes using the SURROUND and DSP buttons.
  • Tuner Operations: Select FM/AM band and tune stations using TUNING UP/DOWN buttons.
  • External Component Connection: Select AUX as the source to enjoy sound from connected external devices.
  • Picture Adjustment: Adjust Brightness, Edges, Color, and Contrast using the CHOICE and cursor buttons.
  • Sleep Timer: Set a timer to automatically turn off the system.
  • DVD Preferences: Access menus for Language, Picture, Audio, Setting, and Rating to customize playback.

Troubleshooting and error codes

PROBLEM POSSIBLE CAUSE SOLUTION
Power does not come on. The power cord is not plugged in. Insert the plug into the socket.
The remote control does not work. • It is too far from the center unit, or is not facing the center unit.
• There is something obstructing the remote sensor.
• The CONTROL VCR or CONTROL TV button has been pressed.
• The battery is flat.
• The battery has been inserted the wrong way round (+/-).
• Sunlight is falling directly on the detector. 		• Come close to the center unit.
• Avoid any obstacles.
• Press DVD, FM/AM or AUX to operate the system. (See page 58)
• Replace the battery.
• Insert the battery correctly.
• Shade the remote control from direct sunlight.
No sound. • There is a short in the speaker cord.
• The audio cord is not connected properly.
• An incorrect source has been selected.
• Muting is on. 		• Reconnect the speaker cord.
• Connect the cord properly. (See page 8.)
• Select the correct source. (See pages 10 to 16.)
• Press MUTING to cancel muting.
Sound is emitted from only one speaker. • The disc is copy-protected CD. • Replace the disc.
No video. • The speaker cord is not connected correctly.
• The video cord is not connected properly.
• TV input selection is incorrect. 		• Connect the cord properly. (See page 7.)
• Connect the cord properly. (See page 9.)
• Select the correct input.
A disc cannot be played. • The system and disc region code numbers are incompatible.
• The disc causes the parental (rating) error. 		• Replace the disc. (See page 22.)
• Enter password to change the parental (rating) level. (See page 57.)
"Error" appears on the TV screen. • The CD-R/RW is not recorded in the audio CD format, MP3 format, or JPEG format. • Replace the disc.
Video and audio are distorted. The disc is dirty.
• A VCR is connected between the center unit and the TV.		 Clean the disc.
Connect the center unit and TV directly.
The moving picture is noisy. • "Pause/Still" mode may not be set appropriately for the current disc. • Select "Field" on "Pause/Still" mode. (See page 54.)
The edge is missing on the video image. • Initial setup (Monitor Type) was incorrect. • Set Monitor Type correctly. (See page 54.)
Continuous static during FM broadcasts. • The received signal is too weak.
• The station is too far away.
• The antenna is not connected correctly. 		• Connect an external FM antenna (see page 5), or contact your dealer.
• Select another station.
• Check the connection. (See page 5.)
The system does not work correctly. • Lightning or electronic noise interferes with operation of the microcomputer.
• Immediately after beginning to heat the room, the unit was moved to a cold location causing condensation to form inside. 		Switch power off, and remove and re-insert the power plug in the socket.
Switch power off and leave the unit a few hours before switching power on again.
The VCR cannot be operated using this remote control. • The remote control is not set for VCR operations.
• The VCR is not a JVC's product. 		• Press CONTROL VCR to operate the VCR. (See page 58.)
• This remote control can operate a JVC's VCR whose remote control code is set to A code.
