Warranty Information
Warranty information is not available in this excerpt.
- Turning the system on/off: Press the Power button (/I AUDIO) on the remote control or the / button on the center unit.
- Selecting the source to play: Use the source buttons on the remote (DVD, USB MEMORY, FM/AM, AUX) or press SOURCE on the center unit repeatedly.
- Adjusting volume: Use AUDIO VOL +/- on the remote or VOLUME +/- on the center unit.
- Listening with headphones: Connect headphones to the PHONES jack; the system automatically enters headphone mode.
- Turning off sound temporarily (Muting): Press MUTING. Press again or adjust volume to restore sound.
- Adjusting brightness: Press DIMMER with SHIFT pressed.
- Sleep Timer: Press SLEEP with SHIFT pressed to set automatic turn-off time.
- Adjusting speaker levels: Press SPK-LEVEL, then use LEVEL +/- to adjust output for each speaker.
- Changing scan mode: Press and hold SCAN MODE for 2 seconds, then use cursor buttons to select NTSC, NTSC PRG, PAL, or PAL PRG.
Troubleshooting and error codes
| PROBLEM | POSSIBLE CAUSE | SOLUTION |
|---|---|---|
| Power does not come on. | The power cord is not connected. | Connect the power cord correctly. (See page 12.) |
| The remote control does not work. | The batteries are exhausted. | Replace the batteries. (See page 6.) |
| The remote control does not work as expected. | Sunlight is shining directly on the remote sensor. | Hide the remote sensor from direct sunlight. |
| The remote control mode is not for the desired source. | Before operation, press one of the source selecting buttons for the desired source. | |
| No sound. | The speaker cord is not connected. | Check the connection. (See pages 8 to 10.) |
| An incorrect source has been selected. | Select the correct source. (See page 15.) | |
| No picture is displayed on the TV screen. | The video cord is not connected correctly. | Connect the cable correctly. (See page 11.) |
| The disc or file is not playable. | Use a playable disc or file. (See pages 3 and 4.) | |
| No picture is displayed on the TV screen, the picture is blurred, or the picture is divided into two parts. | The scan mode is set to “NTSC PRG” or “PAL PRG” though the center unit is connected to the TV which does not support the progressive video input. | Change the scan mode to “PAL” or “NTSC”. (See page 16.) |
| Video and audio are distorted. | The disc is scratched or dirty. | Replace or clean the disc. |
| A VCR is connected between the center unit and the TV. | Connect the center unit and TV directly. (See page 11.) | |
| The picture does not fit the TV screen. | The monitor type is not set correctly. | Set “MONITOR TYPE” properly. (See page 33.) |
| The broadcast is hard to hear because of noise. | Antennas are disconnected. | Reconnect the antennas correctly and securely. (See page 7.) |
| The system suddenly turns off. | The playback level of the current source is too high. | Play back the source with lower volume level. |
