Manual for GR-DVX10 / GR-DVX9
Uploaded: Aug. 10, 2025, 12:34 a.m.
- Charging the Battery Pack: Connect the AC Power Adapter/Charger to the camcorder and an AC outlet. Attach the battery pack to the adapter; the CHARGE indicator will blink, then stay lit when charging is complete.
- Using AC Power: Connect the AC Power Adapter/Charger to the camcorder and an AC outlet.
- Grip Adjustment: Separate the Velcro strap, pass your hand through the loop, grasp the grip, and adjust for easy operation of buttons.
- Viewfinder Adjustment: Set the POWER switch to CAMERA, pull out the viewfinder, and adjust the Dioptre Control for a clear image.
- Date/Time Settings: Navigate through the menu to set the date and time using the MENU wheel.
- Loading/Unloading a Cassette: Power on the camcorder, open the cassette holder cover, insert or remove the cassette, and close the cover.
- Recording Mode Setting: Select the recording mode (SP or LP) via the MENU screen.
- Loading a MultiMediaCard: Ensure the camcorder is off, open the card cover, insert the card, and close the cover.
- Picture Quality/Size Setting: Use the IMAGE SIZE/RES. button to select the desired mode (XGA FINE, XGA STD, VGA FINE, VGA STD).
- Operation Modes: Select CAMERA, OFF, or PLAY/PC using the POWER Switch. Use the Operation Switch for MANUAL (M) or FULL AUTO (A) recording.
- MODE Dial: Choose DUAL, VIDEO, PS, or DSC modes for different recording functions.
- Basic Recording for Video: Set MODE Dial to VIDEO, POWER switch to CAMERA, then press START/STOP to record.
- Snapshot (For Video Recording): Select SNAP MODE via the menu, then press SNAPSHOT button to capture still images.
- Basic Shooting (Snapshot): Set MODE Dial to DSC, POWER switch to CAMERA, press SNAPSHOT halfway to preview, then fully to capture and save to MultiMediaCard.
- Zooming: Use the Power Zoom Lever to zoom in (T) or out (W).
- Recording From The Middle Of A Tape: Play back or use Blank Search to find the spot, then start recording from that point.
- Progressive Mode Recording: Set MODE Dial to PS, POWER switch to CAMERA, then press START/STOP to record jitter-free images.
Troubleshooting and error codes
| Indications | Function |
|---|---|
 |
Displays the battery remaining power. Remaining power level: high Remaining power level: exhausted As the battery power comes close to nil, the battery indicator blinks. When the battery power is exhausted, power turns off automatically. |
|
Appears when no tape is loaded. (☞ pg. 10) |
| CHECK TAPE'S ERASE PROTECTION SWITCH | Appears when the erase protection tab is set to “SAVE” while the POWER Switch is set to "CAMERA". (☞ pg. 10) |
|
Appears if dirt is detected on the heads during recording. Use an optional cleaning cassette. (☞ pg. 94) |
| CONDENSATION OPERATION PAUSED PLEASE WAIT | Appears if condensation occurs. When this indication is displayed, wait more than 1 hour until condensation disappears. |
| TAPE! | Appears if a tape is not loaded when START/STOP is pressed while the POWER Switch is set to “ CAMERA" and the MODE Dial is set to “VIDEO", "PS" or " DUAL". (☞ pg. 17) |
| TAPE END | Appears when the tape ends during recording or playback. (☞ pg. 17) |
| DIFFERENT FORMATTED TAPE | Appears if a tape in another format is loaded. |
| SET DATE/TIME! | • Appears when the date/time is not set. (☞ pg. 9) • Appears when the built-in clock (lithium) battery is discharged and the previously set date/time is erased. (☞ pg. 9) |
| A. DUB ERROR! | Appears if Audio Dubbing is attempted on a blank portion of a tape. (☞ pg. 76) |
| A. DUB ERROR! <CANNOT DUB ON A LP RECORDED TAPE> <CANNOT DUB ON A 16BIT RECORDING> <CHECK TAPE'S ERASE PROTECTION SWITCH> | • Appears if Audio Dubbing is attempted on a tape recorded in the LP mode. (☞ pg. 76) • Appears if Audio Dubbing is attempted on a tape recorded in 16-bit audio. (☞ pg. 76) • Appears if A. DUB ( |
| MEMORY IS FULL | Appears when the MultiMediaCard's memory is full and shooting is not possible. |
