Power
This camcorder has a 2-way power supply system. You can use either the AC adapter or a battery pack. To charge the battery pack, insert it into the camcorder, connect the AC adapter, and plug it into an AC outlet. The CHARGE lamp indicates charging status. During charging, the camcorder cannot be operated.
Grip Adjustment
Adjust the grip strap for a comfortable hold. Ensure your hand can easily reach the recording controls.
Viewfinder Adjustment
Set the power switch to 'A' or 'M' while pressing the lock button. Pull out the viewfinder and turn the Dioptre Adjustment Control until the image is clear.
Tripod Mounting
Align the tripod screw with the camera's mounting socket and tighten. Use a stable tripod and extend its legs for stability.
Date/Time Settings
Set the power switch to 'M' and access the menu. Navigate to DISPLAY, then CLOCK ADJ. to set the date and time. The camcorder has a built-in rechargeable lithium battery for the clock.
Loading/Unloading A Cassette
With the camcorder powered on, slide OPEN/EJECT to open the cassette holder. Insert or remove the tape and press PUSH HERE to close the holder. Be careful not to touch internal components. Ensure the erase protection tab is set to 'SAVE' to protect recordings.
Troubleshooting and error codes
| Indications | Function |
| (Battery indicator) | Displays the battery remaining power. Blinks when power is low. Turns off automatically when exhausted. |
| CHECK TAPE'S ERASE PROTECTION TAB | Appears when the erase protection tab is set to "SAVE" and the camcorder is in VIDEO mode. |
| HEAD CLEANING REQUIRED USE CLEANING CASSETTE | Appears if dirt is detected on the heads. Use an optional cleaning cassette. |
| CONDENSATION OPERATION PAUSED PLEASE WAIT | Appears if condensation occurs. Wait for it to disappear. |
| TAPE! | Appears if no tape is loaded when recording or snapshot is attempted in VIDEO mode. |
| TAPE END | Appears when the tape ends during recording or playback. |
| DIFFERENT FORMATTED TAPE | Appears if a tape in another format is loaded. |
| SET DATE/TIME! | Appears when the date/time is not set or the clock battery is discharged. |
| A. DUB ERROR! | Appears during Audio Dubbing errors (blank portion, LP mode, 16-bit audio, or write-protected tape). |
| MEMORY IS FULL | Appears when the memory card is full and shooting is not possible. |
| INSERT ERROR! | Appears if Insert Editing is attempted on a blank portion or in LP mode. |
| COPYING FAILED | Appears during failed copying operations (e.g., copyguard signals, unformatted card, condensation). |
| MEMORY CARD! | Appears if a memory card is not loaded when SNAPSHOT is pressed in DSC mode. |
| PLEASE FORMAT | Appears when there is a problem with the memory card and it needs to be initialized. |
| NO FILES STORED | Appears if no image or video clip files are stored in the memory card. |
| NO SOUND FILES | Appears if no sound files are stored in the memory card. |
| Unsupported file! | Appears when an unsupported file format is selected. |
| E01-E06 | Error indications showing malfunctions. Turn off and on again. If persists, consult dealer. |
| CARD ERROR! | Appears if the camcorder takes too long to recognize the memory card. Remove and reinsert. If persists, card is corrupted. |
| CHECK CARD'S WRITE PROTECTION SWITCH | Appears when attempting to shoot stills with a copy-protected SD Memory Card. |
