Basic Operation:
Charging the Battery Pack:
Connect the AC adapter to the camcorder and a power outlet. The charging lamp indicates charging status.Recording Video:
Open the lens cover and LCD monitor. Check if the mode is Intelligent Auto (i.A.). Press the START/STOP button to begin recording and again to stop.Playback:
Open the LCD monitor to access playback mode. Use the directional buttons to navigate and select videos for playback.Inserting an SD Card:
Ensure the camcorder is off. Open the cover, insert the SD card with the label facing outward.Basic Settings:
Set the clock and display language via the MENU button and on-screen options.Troubleshooting and error codes
| Problem | Solution |
|---|---|
| Cannot insert the SD card. | Make sure not to insert the card in the wrong direction. |
| Unable to copy to SD card. | Perform media settings. Format the card if it was used on other devices. |
| Sound or video is interrupted. | Playback may be interrupted at connecting sections between scenes. This is not a malfunction. |
| The same image is displayed for a long time. | Replace the SD card or format it. Verify PC system requirements for playback. |
| The motion is choppy. | Replace the SD card or format it. Verify PC system requirements for playback. |
| Cannot find a recorded file. | Cancel date search. Check "REC MEDIA SETTING". Select "PLAYBACK OTHER FILE" if management information is damaged. |
| No date/time display. | Set "ON-SCREEN DISPLAY" and "DISPLAY ON TV" settings accordingly. |
| Images do not appear on the TV properly. | Disconnect and reconnect HDMI cable. Turn the unit off and on again. |
| Images are projected vertically on the TV. | Set "VIDEO OUTPUT" to "4:3". Adjust TV screen accordingly. |
| The image displayed on TV is too small. | Set "VIDEO OUTPUT" to "16:9". |
| When connected to the TV via the HDMI mini cable, proper images and sounds are not output. | Disconnect and reconnect HDMI cable. Turn the unit off and on again. |
| Unable to turn on the power when using the battery pack. | Recharge the battery. Clean battery terminals. Use JVC battery packs. |
| Short usage time even after charging. | Battery deterioration may occur. Replace battery pack. |
| Unable to charge the battery pack. | Check battery terminals. Use an original AC adapter. Turn on the computer when charging via USB. |
| The remaining battery display is not correct. | This can occur in extreme temperatures or with repeated charging. |
| The battery depletes even when the AC adapter is connected. | Use a JVC AC adapter (AC-V11U). |
| Recording cannot be performed. | Set to recording mode with the (Play/Record) button. |
| Recording stops automatically. | Recording stops automatically after 12 consecutive hours. Turn off and on again. Ensure SD card is inserted and "REC MEDIA SETTING" is correct. |
| The focus is not adjusted automatically. | Adjust focus manually in dark or low-contrast conditions. Clean the lens. Cancel manual focus. |
| Zoom does not work. | Zoom is unavailable in time-lapse recording. Set "ZOOM" to "80x/DIGITAL" or "200x/DIGITAL". |
| Mosaic-type noise occurs when recording scenes with fast movements or extreme changes in brightness. | Set "VIDEO QUALITY" to "LS" or "LE" (GZ-HM30/GZ-HM50), or "UXP" or "XP" (GZ-HM430). |
| Vertical lines appear on recorded images. | This occurs when shooting bright light and is not a malfunction. |
| The LCD monitor is difficult to see. | It may be difficult to see in bright areas or under direct sunlight. |
| A band or a ball of bright light appears on the LCD monitor. | Change the unit's direction to avoid the light source. |
| The recorded subject is too dark. | Use backlight compensation, "NIGHTALIVE" scene select, "GAIN UP", or adjust "BRIGHTNESS ADJUST" to '+'. |
| The recorded subject is too bright. | Set "BACKLIGHT COMP." to "OFF" or adjust "BRIGHTNESS ADJUST" to '-'. |
| The color looks strange. (Too bluish, too reddish, etc.) | Wait for natural colors to adjust. Adjust "WHITE BALANCE" to "MANUAL" (FINE/CLOUD/HALOGEN) or "MWB". |
| The color looks different. | Adjust "WHITE BALANCE" to "MANUAL" (FINE/CLOUD/HALOGEN) or "MWB". Ensure "x.v.Color" is set to "ON" on the TV if the camcorder setting is "ON". |
| There are bright or dark spots on the screen. | This is a normal characteristic of LCDs and does not affect recording. |
| The image is grainy. | Digital zoom enlarges the image digitally, which can make it grainy. |
| This unit heats up. | It may become warm during extended use; this is not a malfunction. |
| The language on the display changed. | May occur when connecting to a TV with a different language setting via HDMI mini cable. |
| HDMI-CEC functions do not work properly, and the TV does not work in conjunction with this unit. | Set "HDMI CONTROL" to "OFF". |
| The unit operates slowly when switching between modes, or when switching the power on or off. | Copy files to a computer and erase them from the unit. Make a backup of important recorded data. |
| Error Message? | Follow the instructions for each specific error message (e.g., CHECK LENS COVER, SET DATE/TIME!, COMMUNICATION ERROR, FORMAT ERROR!, etc.). Refer to specific page numbers for detailed solutions. |
| THIS FILE IS PROTECTED | Switch off the "PROTECT/CANCEL" function. |
| CHECK CARD'S WRITE PROTECTION SWITCH | Set the write protect switch of the SD card to off. |
| INSUFFICIENT AVAILABLE SPACE | Delete files, move files to a computer, or replace the SD card. Ensure sufficient free space for seamless video combining. |
| MAXIMUM QUANTITY RECORDING FOLDERS/FILES HAS BEEN REACHED | Move files to a computer or format the media. |
| SCENE QUANTITY EXCEEDED LIMIT | Move files to a computer or format the media. |
| NUMBER OF FOLDERS OVERFLOW | Move files to a computer or format the media. |
| FILE QUANTITY LIMIT EXCEEDED | Move files to a computer or format the media. |
| CAMERA TEMPERATURE IS TOO COLD KEEP CAMERA POWER ON PLEASE WAIT | Keep the unit on to warm up. If the message persists, move to a warm place and try again later. |
| NO FILES | Check "REC MEDIA SETTING". |
