Troubleshooting and error codes

When the unit is not working properly

Resetting this Unit

1 Open the terminal cover.
• Remove the power cord and all connecting cables.
2 Close the LCD monitor to turn off this unit.
3 Press the Reset button gently using an object with pointed tip.

Charging

Unable to charge the battery.
When the battery pack is fully charged, the lamp does not light up.
Be sure to charge using the supplied AC adapter. Malfunction in the unit that occurred due to the use of an AC adapter other than the one provided is not included in the warranty.
Check the connection, then disconnect and reconnect the charging adapter cable.
Charging cannot be performed under low or high temperature environments.
Charge under the room temperature range of 10°C to 35°C. (Under environments beyond the temperature range, charging may stop to protect the battery pack.)
Using a non-original AC adapter may result in damage to this unit. Be sure to use an original AC adapter.

The remaining battery display is not correct.
If this unit is used for long periods of time in high or low temperatures, or if the battery pack is repeatedly charged, the amount of remaining battery may not be displayed correctly.

The battery runs out quickly even after charging.
Be sure to charge using the supplied AC adapter. Malfunction in the unit that occurred due to the use of an AC adapter other than the one provided is not included in the warranty.
The performance of the battery will drop temporarily when the temperature is -10°C to 0°C, this will cause the remaining recording time to shorten.
When the recording time becomes extremely short even when the battery is fully charged, the battery needs to be replaced. For details on replacing the built-in battery (subject to a fee), consult the nearest JVC service center.

Troubleshooting

Power supply

Unable to turn on the power.
The camera does not turn on if the remaining battery power is low.
In this case, charge the battery for more than 40 minutes before turning on the power.

Recording

Recording cannot be performed.
Check the [ ] button.
"Top/Left/Rear Side" ( p. 93)
Set to the recording mode by tapping the [REC] button on the screen.

Recording stops automatically.
Recording stops automatically as it cannot be performed for 12 or more consecutive hours according to specifications. (It may take some time to resume recording.)
Turn off this unit, wait for a while, and turn it on again. (This unit stops automatically to protect the circuit when the temperature rises.)

The continuous shooting speed of still images is slow.
The continuous shooting speed will drop if this function is used repeatedly. Continuous shooting speed may drop depending on the SD card or under certain recording conditions.

The focus is not adjusted automatically.
If you are recording in a dark place or a subject that has no contrast between dark and light, adjust the focus manually.
"Adjusting Focus Manually (FOCUS)" ( p. 29)
Wipe the lens with a lens cleaning cloth.
Cancel manual focus on the manual recording menu.
"Adjusting Focus Manually (FOCUS)" ( p. 29)

Zoom does not work.
Digital zoom is not available in the still image recording mode.
Zoom operation is not available in time-lapse recording. (Simultaneous still image recording and image stabilizer are also not available.)
To use digital zoom, set "ZOOM" in the menu accordingly.
"ZOOM" (p. 79)

Mosaic-type noise occurs when recording scenes with fast movements or extreme changes in brightness.
Set the "VIDEO QUALITY" to "UXP" or "XP" for recording.
"VIDEO QUALITY" ( p. 79)

The inside of the lens is foggy.
Open the terminal cover; close the LCD monitor and leave as is for a while to reduce the temperature.

Preventing fogging inside the lens
• Models with waterproof function are airtight. When the temperature rises during recording, condensation can occur inside the lens due to the internal humidity.
During recording
To prevent the temperature of this unit from rising, we recommend that you use the unit in the following ways.
1 Avoid frequent exposure to direct sunlight.
Record under the shade or use an umbrella. Best if you could keep a wet towel cover the unit.
2 The use of a tripod is recommended.
Long hours of recording while holding the unit in your hands will cause the temperature of the unit to rise.
3 It is better to leave the terminal cover open while recording.
However, the waterproof, dust-proof and shockproof features do not function in this condition. Do take note of the environment when using the camera. (Do not use a wet towel.)
4 Make sure to turn off the power when you are not recording.
When the LCD monitor is closed, the unit turns off.

During charging
It is recommended to charge the unit in a low humidity environment.
The moist air inside the unit can cause condensation.
We recommend that you charge the unit in a room where humidifier is not in use, and in an air-conditioned room during summer.

Troubleshooting
SD Card	Cannot insert the SD card. Make sure not to insert the SD card in the wrong direction. "Inserting an SD Card" ( p. 9) Do not use a miniSD card or microSD card on this unit (even if the card is inserted in an adapter). It may cause malfunction. "Types of Usable SD Card" (p. 9) Unable to copy to SD card. To use a new SD card, or SD card used on other devices, it is necessary to format (initialize) the SD card using "FORMAT SD CARD" from the "SETUP" menu. "FORMAT SD CARD" ( p. 89) When "CHECK CARD'S WRITE PROTECTION SWITCH" appears, release the lock on the SD card. The motion is choppy. Use a high speed SD card (Class 4 or higher). "Types of Usable SD Card" (p. 9) Clean the terminals of the SD card with a dry cotton swab or something similar. Execute "FORMAT SD CARD" in the "SETUP" menu. (All data will be deleted.) "FORMAT SD CARD" ( p. 89) Cannot find a recorded file. "Operation Buttons for Video Playback" (p. 48) "Operation Buttons for Still Image Playback" (p. 53) Select "PLAYBACK OTHER FILE" in the menu. (Video files that have damaged management information can be played back.) "PLAYBACK OTHER FILE" (р. 52) Images are projected vertically on the TV. Set "VIDEO OUTPUT" in the "CONNECTION SETTINGS" menu to "4:3". "VIDEO OUTPUT" ( p. 90) Adjust the TV's screen accordingly. The image displayed on TV is too small. Set "VIDEO OUTPUT" in the "CONNECTION SETTINGS" menu to "16:9". "VIDEO OUTPUT" ( p. 90) When connected to the TV via the HDMI mini cable, proper images and sounds are not output. Images and sounds may not be output properly depending on the TV connected. In such cases, perform the following operations. 1 Disconnect the HDMI mini cable and connect it again. "Connecting via the HDMI Mini Connector" (p. 55)	Playback Sound or video is interrupted. Sometimes playback is interrupted at the connecting section between two scenes. This is not a malfunction. There is no sound. When the Silent mode is used, operation sounds will not be output. Turn off the Silent mode. "Using the Silent Mode" ( p. 23) Set "OPERATION SOUND" in the "SETUP" menu to "ON". "OPERATION SOUND" ( p. 88) Audio sound is not recorded for videos taken in TIME-LAPSE RECORDING. "Recording at Intervals (TIME-LAPSE RECORDING)" ( p. 41) The same image is displayed for a long time. Use a high speed SD card (Class 4 or higher). "Types of Usable SD Card" (p. 9) Clean the terminals of the SD card with a dry cotton swab or something similar. Execute "FORMAT SD CARD" in the "SETUP" menu. (All data will be deleted.) "FORMAT SD CARD" ( p. 89) The motion is choppy. Use a high speed SD card (Class 4 or higher). "Types of Usable SD Card" (p. 9) Clean the terminals of the SD card with a dry cotton swab or something similar. Execute "FORMAT SD CARD" in the "SETUP" menu. (All data will be deleted.) "FORMAT SD CARD" ( p. 89) Verify the system requirements of your PC when using Everio MediaBrowser 4 to play back. "Verifying System Requirements (Guideline)” (p. 64)

Troubleshooting
Screen/Image	The LCD monitor is difficult to see. The LCD monitor may be difficult to see if used in bright areas such as under direct sunlight. Color and brightness of the screen changes and horizontal stripes and flickers appear on screen For images recorded under lighting from fluorescent or mercury lamps, the color and brightness of the screen may change and horizontal stripes and flickers may appear on the screen, but this is not a malfunction. If the image stabilizer has been set to "ON (AIS)", switch to "ON" to improve the condition. "Reducing Camera Shake" (p. 40) A band or a ball of bright light appears on the LCD monitor. Change the direction of this unit to prevent the light source from coming into view. (A band or a ball of bright light may appear when there is a bright light source near this unit, but this is not a malfunction.) The recorded subject is too dark. Use backlight compensation when the background is bright and the subject is dark. "Setting Backlight Compensation" ( p. 31) Use "GAIN UP" in the menu. "GAIN UP" (p. 77) Set "BRIGHTNESS ADJUST" in the recording menu to the "+" side. "Adjusting Brightness" ( p. 30) The recorded subject is too bright. Set the backlight compensation to "OFF" if it is being used. "Setting Backlight Compensation" ( p. 31) Set "BRIGHTNESS ADJUST" in the recording menu to the "-" side. "Adjusting Brightness" ( p. 30) The color looks strange. (Too bluish, too reddish, etc.) Wait for a while until natural colors are achieved. (It may take some time for white balance to be adjusted.) Set "WHITE BALANCE" in the recording menu to "MANUAL". Select from "FINE"/"CLOUD"/"HALOGEN" according to the light source. Select "MWB" and adjust accordingly. "Setting White Balance" ( p. 32) The color looks different. Set "WHITE BALANCE" in the recording menu accordingly. "Setting White Balance" ( p. 32) There are bright or dark spots on the screen. While the LCD monitor screen has more than 99.99% effective pixels, 0.01% of the pixels may be bright spots (red, blue, green) or dark spots. This is not a malfunction. The spots will not be recorded.	Other Problems The buttons on the touch screen do not work. Tap the buttons on the touch screen with your fingers. The buttons may not respond if you touch them with your fingernails or with gloves on. Disable "SCREEN LOCK". You cannot operate the touch panel when "SCREEN LOCK" is enabled. "Locking the Screen" ( p. 34) Save the recorded data before requesting service. 1 Connect to computer using a USB cable. The "SELECT DEVICE" menu appears. 2 Press and hold the START/STOP button for more than 2 seconds. The "PLAYBACK ON PC" appears. 3 Operations are to be performed on the computer after the screen switches. The image is grainy. When digital zoom is used, the image becomes grainy as it is digitally enlarged. This unit heats up. This is not a malfunction. (This unit may become warm when used for a long time.) Stop using the unit if it gets too warm. The language on the display changed. It may occur when you connect this unit to a TV with different language setting using an HDMI mini cable. "Operating in Conjunction with TV via HDMI" (p. 56) When connected to the TV via the HDMI mini cable, proper images and sounds are not output. Images and sounds may not be output properly depending on the TV connected. In such cases, perform the following operations. 1 Disconnect the HDMI mini cable and connect it again. 2 Turn off and on this unit again. "Connecting via the HDMI Mini Connector" (p. 55) HDMI-CEC functions do not work properly, and the TV does not work in conjunction with this unit. TVs may operate differently depending on the specifications, even if they are HDMI-CEC compliant. Therefore, the HDMI-CEC functions of this unit cannot be guaranteed to operate in combination with all the TVs. In such cases, set "HDMI CONTROL" to "OFF". "HDMI CONTROL" ( p. 90) The unit operates slowly when switching between video mode and still image mode, or when switching the power on or off. It is recommended that you copy all videos and still images onto your computer, and erase the files from this unit. (If there are many recorded files on this unit, it takes time for the unit to respond.)

Troubleshooting
Editing/Copying	Unable to delete file. Files (videos/still images) that are protected cannot be deleted. Release protection before deleting the file. "Protecting Files" ( p. 59)	Computer Unable to copy files to the computer's HDD. If the provided software Everio MediaBrowser 4 is not installed, some functions may not work properly. "Installing the Provided Software (Built-in)" (p. 67) Before making backup, make sure that enough free space is left in the computer's hard disk (HDD). Unable to copy files to DVD or Blu-ray disc with a PC. To record to discs, a recordable DVD or Blu-ray drive is required for the computer in use. Cannot upload the file to YouTube. Check if you have created an account with YouTube. (You need a YouTube account to upload files to YouTube.) Changing videos to the file format for uploading cannot be performed on this unit. Refer to the help file of the provided software Everio MediaBrowser 4 I am using a Mac computer. Load the files to a Mac computer using the following method. "Copying to Mac Computer" (p. 75) The computer cannot recognize the SDXC card. Confirm and update the OS of your computer. "When your computer cannot recognize the SDXC card" ( p. 10)

Troubleshooting
THIS FILE IS PROTECTED	Switch off the "PROTECT/CANCEL" function in the "EDIT" menu. "Protecting Files" ( p. 59)
CHECK CARD'S WRITE PROTECTION SWITCH	Set the write protect switch of the SD card to off.
INSUFFICIENT AVAILABLE SPACE	Delete files, or move files to a computer or other devices. Replace the SD card with a new one.
RECORDABLE MANAGEMENT CAPACITY LEVEL HAS BEEN REACHED	1 Move the files or folders to a computer or other device. (Back up your files.) 2 Select "FILE + MANAGEMENT NO" in "FORMAT BUILT-IN MEM." or "FORMAT SD CARD" of the "SETUP" menu. (All data on the built-in memory or SD card will be deleted.) "FORMAT SD CARD" ( p. 89)
SCENE QUANTITY EXCEEDED LIMIT	1 Move the files or folders to a computer or other device. (Back up your files.) 2 Select "FILE + MANAGEMENT NO" in "FORMAT BUILT-IN MEM." or "FORMAT SD CARD" of the "SETUP" menu. (All data on the built-in memory or SD card will be deleted.) "FORMAT SD CARD" ( p. 89)
NUMBER OF FOLDERS OVERFLOW	1 Move the files or folders to a computer or other device. (Back up your files.) 2 Select "FILE + MANAGEMENT NO" in "FORMAT BUILT-IN MEM." or "FORMAT SD CARD" of the "SETUP" menu. (All data on the built-in memory or SD card will be deleted.) "FORMAT SD CARD" ( p. 89)
FILE QUANTITY LIMIT EXCEEDED	1 Move the files or folders to a computer or other device. (Back up your files.) 2 Select "FILE + MANAGEMENT NO" in "FORMAT BUILT-IN MEM." or "FORMAT SD CARD" of the "SETUP" menu. (All data on the built-in memory or SD card will be deleted.) "FORMAT SD CARD" ( p. 89)
RECORDING CANCELLED	Reset this unit. "Resetting this Unit" ( p. 98) Protect the unit from vibration and shock.
CAMERA TEMPERATURE IS HIGH PLEASE TURN CAMERA OFF TO ALLOW IT TO COOL DOWN PLEASE WAIT	Turn off the power of this unit, let and it cool down before turning on the power again.
