Brand: JVC
Category: Camcorder
Document Type: Manual
Language: EN
Manual for GZ-RX515
Uploaded: Aug. 10, 2025, 12:37 a.m.
Warranty Information
None
- Getting Started: Covers verifying accessories, turning the unit on/off, opening the terminal cover, charging the battery, and resetting the unit. It also details Quad Proof features, maintenance after use, grip adjustment, attaching core filters, inserting/removing SD cards, and using the touch screen.
- Recording: Explains taking videos in Auto Mode, including indications for video recording, touch screen operations, and how to start/stop recording.
- Playback: Details playing back videos and still images, including normal playback, marking playback, digest playback, and connecting to a TV.
- Wi-Fi Capabilities: Covers operating the unit using Wi-Fi, including direct connection and using access points, as well as smartphone applications.
- Settings Menu: Guides through navigating and using the various menus for recording, playback, setup, and connection settings.
- Troubleshooting: Provides solutions for common issues such as inability to turn on the unit, charging problems, display errors, SD card issues, and recording/playback interruptions.
Troubleshooting and error codes
| When the unit is not working properly | Troubleshooting Steps |
|---|---|
| Resetting this Unit | 1. Open the terminal cover. Remove the power cord and all connecting cables. 2. Close the LCD monitor to turn off this unit. 3. Press the Reset button gently using an object with pointed tip. |
| Charging | Unable to charge the battery: Ensure using the supplied AC adapter. Check connections. Charge within the temperature range of 10°C to 35°C. Charging is not possible with progressive (60p) recording or Wi-Fi function. |
| The remaining battery display is not correct. | If the unit is used for long periods in high/low temperatures, or if the battery is repeatedly charged, the battery level may not be displayed correctly. |
| The battery runs out quickly even after charging. | Ensure using the supplied AC adapter. Battery performance drops temporarily between -10°C to 0°C. Battery may need replacement if recording time becomes extremely short. |
| Power supply | Unable to turn on the power: Charge the battery for at least 40 minutes before turning on the power if the battery is low. |
| Recording | Recording cannot be performed: Check the button. Set to recording mode by tapping the REC button. |
| Recording stops automatically. | Recording stops automatically after 12+ consecutive hours. Turn off, wait, and turn on again. Unit stops automatically to protect the circuit when temperature rises. |
| The continuous shooting speed of still images is slow. | Speed may drop with repeated use, depending on the SD card, or under certain recording conditions. |
| The focus is not adjusted automatically. | Adjust focus manually in dark places or low-contrast subjects. Wipe the lens. Cancel manual focus. |
| Zoom does not work. | Digital zoom is not available in still image recording or time-lapse recording. Set "ZOOM" in the menu. |
| Mosaic-type noise occurs when recording scenes with fast movements or extreme changes in brightness. | Set "VIDEO QUALITY" to "UXP" or "XP" for recording. |
| The inside of the lens is foggy. | Open terminal cover, close LCD monitor, and leave for a while to reduce temperature. |
| Screen/Image | LCD monitor difficult to see: In bright areas, it may be difficult to see. |
| Color and brightness change, horizontal stripes and flickers appear: | For images recorded under fluorescent/mercury lamps. Not a malfunction. If image stabilizer is set to "ON (AIS)", switch to "ON". |
| A band or ball of bright light appears on LCD monitor: | Change unit direction to prevent light source from entering view. Not a malfunction. |
| Recorded subject too dark: | Use backlight compensation, "LIGHT", or "GAIN UP" in the menu. Adjust "BRIGHTNESS ADJUST" to "+". |
| Recorded subject too bright: | Set backlight compensation to "OFF". Adjust "BRIGHTNESS ADJUST" to "-". |
| Color looks strange (bluish, reddish): | Wait for natural colors to be achieved. Set "WHITE BALANCE" to "MANUAL" or adjust accordingly. |
| Color looks different: | Set "WHITE BALANCE" accordingly. |
| Bright or dark spots on screen: | 0.01% of pixels may have spots. Not a malfunction. Spots will not be recorded. |
| Other Problems | Buttons on touch screen do not work: Tap with fingers. Disable "SCREEN LOCK". |
| Image is grainy: | Occurs when digital zoom is used. |
| Unit heats up: | Not a malfunction. Stop using if it gets too warm. |
| Language on display changed: | May occur when connecting to TV via HDMI. Adjust language setting on TV. |
| When connected to TV via HDMI, proper images and sounds not output: | Disconnect and reconnect HDMI cable. Turn unit off and on again. Set "HDMI CONTROL" to "OFF". |
| HDMI-CEC functions do not work properly: | TVs may operate differently. Set "HDMI CONTROL" to "OFF". |
| Unit operates slowly: | Copy all files to computer and erase from unit. |
| SD Card | Cannot insert SD card: Ensure correct orientation. Do not use miniSD/microSD cards. |
| Unable to copy to SD card: | Set "REC MEDIA" to SD card. Format the SD card using "FORMAT SD CARD". Release write protection. |
| Playback | Sound or video is interrupted: Not a malfunction, occurs at scene transitions. |
| There is no sound: | Turn off "SILENT MODE" or set "OPERATION SOUND" to "ON". Audio not recorded for TIME-LAPSE RECORDING. |
| Same image displayed for a long time: | Use a high-speed SD card. Clean terminals. Format SD CARD. Verify PC system requirements. |
| Motion is choppy: | Use a high-speed SD card. Clean terminals. Format SD CARD. Verify PC system requirements. |
| Cannot find a recorded file: | Change playback media. Select "PLAYBACK OTHER FILE". |
| Images do not appear on TV properly: | Disconnect/reconnect cable. Reset unit. Set "VIDEO OUTPUT" to "4:3". |
| Image displayed on TV is too small: | Set "VIDEO OUTPUT" to "16:9". |
| When connected to TV via HDMI, proper images and sounds are not output: | Disconnect/reconnect HDMI cable. Turn unit off and on again. |
| Editing/Copying | Unable to delete file: Release protection before deleting. |
| Unable to copy to SD card: | Set SD card write protection switch to off. |
| Computer | Unable to copy files to computer's HDD: Install provided software. Ensure sufficient free space. |
| Unable to copy files to DVD or Blu-ray disc with PC: | Requires a recordable DVD or Blu-ray drive. |
| Cannot upload file to YouTube: | Check YouTube account. Upload format conversion not on unit. Refer to software help file. |
| I am using a Mac computer: | Load files using the specified method. |
| Computer cannot recognize SDXC card: | Confirm and update computer OS. |
| The computer cannot recognize the SDXC card: | Confirm and update the OS of your computer. |
| This unit does not function properly and error messages appear. | Close monitor screen to turn off power, remove AC adapter, press Reset button. If problem persists, contact dealer. |
| CHARGE lamp and POWER/ACCESS lamp are blinking and operation is disabled | Close monitor screen to turn off power, remove AC adapter, press Reset button. If problem persists, contact dealer. |
| Error Message? | SET DATE/TIME!: Reset clock after battery depletion. |
| COMMUNICATION ERROR | Reconnect USB cable. Turn devices off/on, reset unit. |
| FORMAT ERROR! | Check procedure, perform again, reset unit. |
| ERROR IN BUILT-IN MEMORY! | Reset unit. Backup files and format BUILT-IN MEM. |
| MEMORY CARD ERROR! | Check card support. Reset unit. Re-insert SD card. Clean terminals. Backup files and format SD CARD. |
| NOT FORMATTED | Select "OK", then "YES" to format. |
| RECORDING FAILURE | Reset unit. |
| CANNOT TAKE MORE STILL IMAGES AT THIS TIME | Stop video recording before taking still images. |
| PLAYBACK FAILED | Remove/re-insert SD card. Clean terminals. Insert card before power on. Avoid impact/vibration. |
| UNSUPPORTED SCENE! | Use files recorded with this unit. |
| UNSUPPORTED FILE! | Use files recorded with this unit. |
| THIS FILE IS PROTECTED | Switch off "PROTECT/CANCEL" function. |
| CHECK CARD'S WRITE PROTECTION SWITCH | Set write protect switch of SD card to off. |
| INSUFFICIENT AVAILABLE SPACE | Delete files, move files to computer, or replace SD card. Check free space before combining videos. |
| RECORDABLE MANAGEMENT CAPACITY LEVEL HAS BEEN REACHED | Move files to computer. Format BUILT-IN MEM. or SD CARD. |
| SCENE QUANTITY EXCEEDED LIMIT | Move files to computer. Format BUILT-IN MEM. or SD CARD. |
| NUMBER OF FOLDERS OVERFLOW | Move files to computer. Format BUILT-IN MEM. or SD CARD. |
| FILE QUANTITY LIMIT EXCEEDED | Move files to computer. Format BUILT-IN MEM. or SD CARD. |
| NO FILES | Check "REC MEDIA" settings. Ensure files are not recorded to other media. |
| RECORDING CANCELLED | Set "REC MEDIA" to SD CARD, record to SD card. Reset unit. Protect from vibration/shock. |
| CAMERA TEMPERATURE IS HIGH PLEASE TURN CAMERA OFF TO ALLOW IT TO COOL DOWN PLEASE WAIT | Turn off unit, let it cool down before turning on again. |
