Warranty Information
JVC provides a limited warranty for 1 year on parts and 90 days on labor for this product.
Installing Your New Unit
- Basic Connections: Connect antenna, AC power cord, and then connect to TV via RF, AV, S-VIDEO, or Component Video connections. Set VCR channel if using RF connection.
- Plug & Play Set: Connect antenna and AC power cord. The unit automatically sets clock and tuner channels.
- Monitor Set (DVD Deck): Select the correct aspect ratio (16:9, 4:3LB, 4:3PS) for your TV.
- Language Set: Choose the on-screen display language for both VCR and DVD decks.
- Menu/Audio/Subtitle Language Set (DVD Deck): Select preferred languages for DVD menu, audio, and subtitles.
- Child Lock: Press and hold POWER for 10 seconds to lock/unlock the unit's operation.
- Scan Mode Set (DVD Deck): Switch between progressive (480p) and interlaced (480i) scan modes for enhanced picture quality.
Troubleshooting and error codes
| SYMPTOM | POSSIBLE CAUSE | CORRECTIVE ACTION |
| POWER | ||
| 1. No power is supplied to the unit. | The AC power cord is disconnected. | Connect the AC power cord. |
| 2. The Remote won't function. | The batteries are discharged. | Replace the dead batteries with new ones. |
| TAPE TRANSPORT (VCR deck) | ||
| 1. During recording, the tape does not run. The counter display blinks on the front display panel. | The unit is in the Record Pause mode. | Press PLAY to resume recording. |
| 2. The tape will not rewind or fast-forward. | The tape is already fully rewound or fast-forwarded. | Check the cassette. |
| PLAYBACK (VCR deck) | ||
| 1. The VCR deck can not be operated. | The VCR deck is not selected. | On the unit: Press VCR/DVD repeatedly so that the VCR indicator lights up. On the Remote: Press VCR so that the VCR indicator lights up. |
| 2. The playback picture does not appear while the tape is running. |
• If you are using the RF connection, the TV receiver's channel selector is not set to the VCR channel. - the unit's VCR channel has not been correctly set. • If you are using the AV, S-VIDEO* or Component Video* connection, the TV receiver is not set to the AV mode. * (DVD deck only) |
If you are using the RF connection, set the TV receiver to the VCR channel. - perform "Set the VCR channel." (pg. 14). If you are using the AV or S-VIDEO*, Component Video* connection, set the TV to its AV mode. * (DVD deck only) |
| 3. Noise appears during visual search. | This is normal. | Try manual tracking. (pg. 32) |
| 4. Noise appears during normal playback. | The automatic tracking mode is engaged. | Try manual tracking. (pg. 32) |
| 5. The playback picture is blurred or interrupted while TV broadcasts are clear or "USE CLEANING CASSETTE" message appears on the screen. | • The video heads may be dirty. | Use a dry cleaning cassette ECL-3F, or consult your JVC dealer. |
| 6. Breaks are noticeable in Hi-Fi soundtrack. | The automatic tracking mode is engaged. | Try manual tracking. (pg. 32) |
| PLAYBACK (DVD deck) | ||
| 1. The button do not work. | The operation is prohibited on the placed disc. | — |
| 2. The DVD deck can not be operated. | The DVD deck is not selected. | On the unit: Press VCR/DVD repeatedly so that the DVD indicator lights up. On the Remote: Press DVD so that the DVD indicator lights up. |
| 3. " " appears on the TV screen. | The operation is prohibited on the placed disc. | — |
| 4. "REGION CODE ERROR!" appears on the TV screen. | • The disc's region number does not match that of the unit. | Use the discs whose region number includes "ALL" or "1". (pg. 7) |
| 5. The disc cannot be played back. | • The disc's region number does not match that of the unit. • This type of the disc cannot be played back. • The disc is not placed properly. |
Use the discs whose region number includes "ALL" or "1". (pg. 7) See "Unplayable Discs" (pg. 7). Remove the disc, then place the disc properly in the disc tray. (pg. 9, "Placing a Disc") |
| 6. The language is not played back as you set. | • The disc does not contain the language you set. | With some discs, the language should be set on the top menu. (pg. 43) |
| 7. Changing audio/subtitle language is not possible. | • The disc does not contain the audio/subtitle in the multiple languages. | With some discs, the language should be set on the top menu. (pg. 43) |
| 8. The subtitles do not appears on the TV screen. | • The disc does not contain the subtitles. • The subtitle display is set to off. • A-B Repeat Playback is in progress. (pg. 51) |
Set the subtitles display to on. (pg. 54) The subtitles recorded around A-B point may not appear. |
| 9. Angle cannot be changed. | The scene is not recorded from the multiple angles. | — |
| MP3 Playback (DVD deck) | ||
| 1. A disc cannot be played. | • No MP3 files are recorded to the disc. • MP3 files do not have the correct file extension in their file names. • MP3 files are not recorded in a format compliant with ISO 9660 Level 1 or 2. • The different types of files are recorded to the disc. |
Replace the disc. Add correct file extension (.mp3, .MP3 or any uppercase and lowercase combination such as ".Mp3") to their file names. Replace the disc. (Record MP3 files using a compliant application.) The disc which contains the different types of files may not be played because of its disc characteristics or recording conditions. |
| 2. Not MP3 files but JPEG files are played. | The FILE TYPE setting is set to "STILL PICTURE". | When both MP3 files and JPEG files are recorded to a disc, set "FILE TYPE" to "AUDIO" to play MP3 files. (pg. 78) |
| 3. The MP3 control display appears on the TV screen, but no operation can be performed. | • No MP3 files or JPEG files are recorded to the disc, or the disc is an unplayable disc (such as CD-ROM). | Replace the disc. (pg. 9) |
| JPEG Playback (DVD deck) | ||
| 1. A disc cannot be played. | • No JPEG files are recorded to the disc. • JPEG files do not have the correct file extension in their file names. • JPEG files are not recorded in a format compliant with ISO 9660 Level 1 or 2. |
Replace the disc. Add correct file extension (.jpg, .jpeg, .JPG, .JPEG or any uppercase and lowercase combination such as ".Jpg") to their file names. Replace the disc. (Record JPEG files using a compliant application.) |
| 2. Not JPEG files but MP3 files are played back. | The FILE TYPE setting is set to "AUDIO". | When both MP3 files and JPEG files are recorded to a disc, set "FILE TYPE" to "STILL PICTURE" to play JPEG files. (pg. 78) |
| RECORDING (VCR deck) | ||
| 1. Recording cannot be started. | • There is no cassette loaded, or the cassette loaded has had its record safety tab removed. | Insert a cassette, or using adhesive tape, cover the hole where the tab was removed. |
| 2. TV broadcasts cannot be recorded. | "F-1" has been selected as the input mode. | Set to the desired channel. |
| 3. Tape-to-tape editing is not possible. | The source (another video recorder, camcorder) has not been properly connected. | Confirm that the source is properly connected. |
| 4. Camcorder recording is not possible. | • All necessary power switches have not been turned on. • The input mode is not correct. |
Confirm that all units' power switches are turned on. Set the input mode to "F-1". |
| 5. " " and " " on the front display panel won't stop blinking. | The camcorder has not been properly connected. The input mode is not correct. |
Confirm that the camcorder is properly connected. Set the input mode to "F-1". |
| The end of the tape was reached during recording. | The program may not have been recorded in its entirety. Next time make sure you have enough time on the tape to record the entire program. | |
