Manual for AV-27D800

Manual for AV-27D800

Brand: JVC

Category: Television

Document Type: Manual

Language: EN

Uploaded: Nov. 21, 2025, 6:21 p.m.

Warranty Information

This limited warranty is valid for one year for parts and labor, covering defects in materials and workmanship.

Remote Control

  • Use AA batteries. Replace when erratic.

Power

  • Set TV/CATV switch to TV (or CATV for cable box).
  • Press POWER button. "Plug In Menu" appears on first use.
  • On Timer lamp glows red when powered on.

Volume

  • Use VOLUME -/+ buttons.
  • Press MUTING to mute. Press again to restore.

Channels

  • 10-key direct access (use 0 then number for single digits, 100+ for above 99).
  • Scan with CHANNEL +/- buttons.
  • RETURN+ returns to previous channel.
  • Hold RETURN+ to program a return channel.

CATV & VCR Setup

  • Follow on-screen menus to program remote for cable box/VCR.
  • Use Search Codes Function if brand not listed.

GUIDE Plus+ GOLD Setup

  • Follow on-screen prompts for country, Zip Code, cable/VCR connection.
  • Initial download may take up to 24 hours.

OnScreen Menus

  • Use MENU, UP/DOWN (▲▼) and LEFT/RIGHT (◀▶) buttons to navigate.
  • EXIT leaves menus.

Troubleshooting and error codes

PROBLEMS CHECK
No power
  • See if the power cord became unplugged.
  • Perhaps you have experienced a blown circuit breaker or fuse or a power outage.
No picture or sound
  • The antenna could be disconnected.
  • The Input mode (TV or video) could not be set properly, refer to page 44.
  • The tuner mode (in the menu selection) could be set improperly, refer to page 17.
  • The station may be having difficulties, check to see if other channels are operating normally.
Remote control is not operating
  • Check that the batteries are still working and properly installed.
  • Make sure there are no objects blocking a clear path from the remote to the TV.
  • Check that the 2-way mode selector switch is in the proper position – set to TV to view television.
You cannot select a certain channel
  • Maybe you are too far from the TV, you must be within 23 feet (or 7 meters).
  • Make sure the channels are programmed. See Channel Summary, page 34.
  • Perhaps the channel is locked, select it with the 10 key pad and follow instructions.
Power turns off
  • Perhaps the On/Off Timer is set, press the power button, check page 41.
  • The power was interrupted or the power cord unplugged.
  • The Sleep Timer may be set, see page 43.
The clock is wrong
  • The clock needs to be reset. See page 18.
Poor color quality
  • Tint and color may be improperly adjusted. Check page 39.
  • Video Status mode may be set to an inappropriate setting. Check page 39.
Lines or streaks across the screen
  • There could be interference from another energy consuming appliance, such as a computer, another TV or VCR. Move any other such appliances farther away from the TV.
Spotted picture
  • There could be interference from a running high wattage appliance such as a hair-dryer, vacuum cleaner, or neon sign. You will have to move the antenna away from the source of the interference or change it to a coaxial cable which is less prone to interference.
Double picture (Ghosts)
  • A building or airplane can reflect the original signal producing a second, delayed one. Adjust the antenna position.
Snowy picture/ Image noise
  • The antenna may be damaged, disconnected or turned. Check the antenna connection, pages 7 to 8. If it is damaged, you will have to replace it.
Screen is 80% black
  • Closed Caption Text Mode is on.
SOUND
Bilingual or stereo programs cant be heard
  • Make sure the MTS mode is properly set. Refer to page 40 for details on setting MTS Modes.
No sound from TV speakers at all
  • TV Speakers may be turned off in the menu, see page 42.
NOT A PROBLEM DON'T WORRY ABOUT THIS, IT'S NORMAL
Static electricity
  • It is normal to feel a surge of static electricity if you brush over or touch the screen.
Occasional crackling sounds
  • It is normal for the TV to emit crackling sounds when turned on or off. Unless the sound or pic-ture become abnormal, this is fine.
