Manual for LT-24CM79W

Basic Operating

The joystick function button at the rear of the monitor allows for simple operation of the monitor's functions. Pressing the button switches the monitor on or off. Moving the button right displays the OSD main menu, moving it left returns to the upper menu or exits the OSD menu. Moving up or down adjusts values or selects options. In VGA signal mode, moving right automatically executes the "Image Auto Adjust" function. Moving right when not in the OSD menu also acts as a fast button for ECO settings (STANDARD/TEXT/GAME/MOVIE/FPS/RTS) and game settings.

Eco Friendly Function

The unit features an ECO-Power mode that automatically switches the monitor to off mode if no input signal is received for several seconds. The monitor will switch back on automatically when an HDMI or VGA signal is received. For long periods of inactivity, disconnect the monitor from the mains socket.

Customizing Settings

To access the OSD main menu, move the joystick function button to the left. Use the buttons to navigate menus and sub-menus, adjusting settings to your preference. Move the button left to confirm settings or exit menus. Options include Brightness, Contrast, ECO modes, Dynamic Contrast Ratio (DCR), Hue, Saturation, Image position and clock (VGA signals only), Phase (VGA signals only), Aspect ratio, Colour Temperature, Red, Green, Blue colour adjustments, Language selection, OSD position, OSD timer, Transparency, Image Auto Adjust (VGA signals only), Color Auto Adjust (VGA signals only), Reset to factory settings, Signal Source selection (VGA/HDMI), and Eye Saver mode.
