Manual for LT-20DA6SK

Manual for LT-20DA6SK

Brand: JVC

Category: TV

Document Type: Manual

Language: EN

Uploaded: Nov. 21, 2025, 8:18 p.m.

Warranty Information

Warranty information not explicitly stated in the provided pages.

Basic Operations

  • Volume Setting: Press "+" or "-" buttons to increase or decrease volume.
  • Programme Selection: Press "P^" or "PV" buttons to select the next or previous programme, or use the digit buttons for direct access.
  • Switching Input Mode: Press the TV/AV/OK button to change input modes (e.g., TV, AV, EXT-1, EXT-2, PC).
  • Entering Main Menu: Press the "MENU" button to access the TV's menu system for picture, sound, features, installation, etc.

Everyday Operation

  • TV/DTV Button: Switches between digital terrestrial broadcasting (DVB-T) and analogue broadcasting.
  • Information Banner: Displays channel and programme information for a few seconds after changing channels or when the "i" button is pressed.
  • Electronic Programme Guide (EPG): Press the "GUIDE" button to view a 7-day programme guide and set reminders.
  • Subtitles: Press the "SUBTITLE" button to turn subtitles ON or OFF.
  • Digital Teletext: Press the "TEXT" button to access digital teletext.

Troubleshooting and error codes

Problem Possible Cause Solution
Can not turn the TV on? TV/VCR/DVD switch is not set to TV position. Set the TV/VCR/DVD switch to TV position.
TV may go to stand-by mode. If you can turn the TV on again, it is not a problem.
Can not turn the TV off? TV/VCR/DVD switch is not set to TV position. Set the TV/VCR/DVD switch to TV position.
Colours of image on screen are abnormal Incorrect TV system selected. Check if the correct TV system is selected.
Interference from nearby equipment or poor aerial connection. Check for interference from loudspeakers, non-earthed audio equipment, or neon lights. Ensure the TV set or house aerial is not too close to these. Change the direction of the aerial.
Mountains or high buildings causing ghost images. Sometimes changing the aerial direction can improve picture quality.
Incorrect frequency entered for Teletext. Check if the correct frequency has been entered.
Two peripherals connected simultaneously. Disconnect one of the peripherals.
No Image on Display Screen Aerial not connected properly or is damaged. Check if the aerial is connected properly, if plugs are tight, and if the aerial cable is damaged. Use suitable plugs. Consult your dealer if in doubt.
TV is not receiving any transmission. Ensure the aerial is connected correctly. Press the correct buttons on the remote control. Try again.
PC Picture does not appear D-SUB cable is not connected properly. Check the D-SUB cable connection.
PC resolution is not set correctly. Check PC's resolution settings. Refer to page 43 for supported modes.
No Sound Sound may have been interrupted by the "MUTE" button. Check if the "MUTE" button was pressed.
External speakers are not connected. Check if external speakers are connected.
Sound from only one speaker Balance is set to one extreme. Adjust the balance in the Sound menu.
Remote Control not responding Batteries are exhausted. Replace the batteries.
Wrong menu selected. Press "MENU" to return to the normal screen or "BACK" to return to the previous menu.
TV suddenly stops responding Temporary issue. Disconnect the TV's power cord from the AC outlet and reconnect it.
Internal failure. If the above does not work, switch off, remove the mains plug and call service personnel. Do not attempt to repair yourself.
Bad picture (in digital mode) Poor reception in the area. This TV can receive Digital and Analogue terrestrial broadcasting. Reception may vary depending on your location. If the picture freezes or shows block effects, there may be a reception problem. Contact your service provider.
