REMOTE CONTROL OPERATION

  • When the amplifier is connected with the T-1001 tuner, DP-1001 CD player, X-1001 cassette deck, GE-1001 equalizer and DM-1001 MD recorder through system control cords, these components can be operated from the remote control unit provided with the amplifier.
  • For the functions of the keys, refer to the instruction manuals of the components.

NOTE RELATED TO TRANSPORTATION AND MOVEMENT

  1. Turn the power ON, but do not load a disc.
  2. Wait a few seconds and verify that the display shown appears.
  3. Turn the power OFF.

TEST MODE

  • Setting the test mode: Short-circuit the test pins (X32-).
  • Can be initiated with short-circuiting the test pins when tray is OPEN.
  • If unit is in test mode, TRACK No. displays "05".
