Warranty Information
Refer to the model and serial numbers whenever you call upon your dealer for information or service.
- Preparation: Set the POWER ON/OFF switch to the ON position.
- Selecting the desired input: Use the INPUT SELECTOR keys on the remote or the INPUT key on the main unit to select the input source (Tuner, VCR, SAT/CABLE, FRONT, DVD/CD, TV).
- Volume adjustment: Use the VOLUME CONTROL knob on the main unit or the VOLUME keys on the remote to adjust the volume.
- Muting the sound temporarily: Press the MUTE key on the remote. Press again or adjust volume to resume.
- Listening through headphone: Insert headphones into the PHONES jack. The unit automatically switches to stereo mode.
- Selecting the DSP mode: Press the LSTN M. key repeatedly to cycle through available sound modes (DOLBY PL II MOVIE, DOLBY PL II MUSIC, DOLBY PRO LOGIC, etc.).
- Selecting the NIGHT mode: Press the SOUND/NIGHT key, then the TRIM (▲/▼) key to toggle NIGHT ON or NIGHT OFF.
- Receiving broadcast station: Select the TUNER input, then the broadcast band (FM/AM), and a tuning mode (AUTO or MANUAL). Use P.CALL keys or numeric keys to select a preset station.
- Storing broadcast stations: Select a station, press ENTER, select a preset number, and press ENTER again.
Troubleshooting and error codes
| Symptom | Cause | Remedy |
|---|---|---|
| Sound is not produced. | The speaker cords are disconnected. | Connect properly referring to "System connection". |
| The MUTE switch of remote control unit is switched ON. | Switch MUTE OFF. | |
| The headphone plug is inserted into the jack. | Unplug the headphone plug. | |
| The volume control of this set is not ad- justed properly. | Set the sound volume to an appropriate level. | |
| Sound is not produced from the left or right speakers. | The speaker cords are disconnected. | Connect properly referring to "System connection". |
| Radio stations cannot be received. | The antennas have not been connected. | Connect antennas. |
| A proper broadcasting band has not been selected. | Select a band. | |
| The frequency of the station to be received is not tuned. | Tune to the frequency of the desired station. | |
| Noise interferes. | Car ignition noise. | Install the outdoor antenna in an apart position from the road. |
| The accessory FM indoor antenna is being used. | Use the outdoor antenna. | |
| Influence of an electric appliance. | Switch the suspected electric appliance OFF. | |
| A TV set is installed near the system. | Install the TV or the system at an increased distance between them. | |
| A station has been preset but it can- not be received by pressing the P.CALL key. | The frequency of the preset station is not tunable. | Preset stations with tunable frequencies. |
| The preset memory has been cleared because the power cord has been unplugged for a long period or operated to reset. | Preset stations again. | |
| Standby condition is reached by power ON. | • The speaker cord connection is not correct or the operation of the microcomputer temporarily has become abnormal. | Reset the microcomputer. Check the speaker connection. If this does not help, contact your dealer for service. |
| Standby condition is reached suddenly while listening to music. | • The temperature protection inside the unit has operated because of an excessive volume. | Leave the unit for about 15 minutes in standby condition to cool down, and then perform power ON. During standby, the standby indicator will flash faster than normal, but when it goes out, the unit has returned to normal condition. If normal return is not obtained even when this operation has been repeated, contact your dealer for service. |
| No sound from the surround speakers | • The LISTEN mode is STEREO. | Select Surround with the LSTN M. key. |
