Brand: KENWOOD
Category: Dishwasher
Document Type: Manual
Language: EN
Manual for KDW8ST2A
Uploaded: Nov. 21, 2025, 9 p.m.
Manual Publish Date: 2009-08-28
Warranty Information
DSG Retail Limited is responsible for after sales service. Contact their product support line for queries.
- Before Operating: Read instructions, remove packaging, open/close door correctly, identify unsuitable items for washing.
- Loading the Dishwasher: Prepare dishes by removing residues, load upper and lower baskets with consideration for spray arm rotation, place cutlery in the basket.
- Starting a Wash Cycle: Ensure power and water supply are on, load dishes, add detergent, select programme, close door, and the cycle will begin.
- Cleaning After Use: Clean exterior (door, seals, control panel) and interior (filters, spray arms) regularly.
- Frost Precaution: Disconnect and empty if temperature is below 0°C.
- Maintenance: For prolonged non-operation, disconnect and leave door slightly open.
Troubleshooting and error codes
| Codes | Possible Causes | Remedy |
|---|---|---|
| E1 | Water tap is not turned on. Low water pressure (<0.04MPa) Flow meter is broken. The wire terminals which connect the flow meter are loose. |
Turn on the water tap. Turn on the water tap and ensure it is fully on. |
| E3, E6, E7 | The temperature sensor is broken. Heater element is broken. The wire terminal connected to the heater is loose. The wire terminal connected to the temperature sensor is broken. The wire terminal connected to the temperature sensor is short circuited or open circuited. |
|
| E4 | The tank is leaking. The hose is leaking. The float switch is broken or PCB is faulty. |
|
