Basic Operation Summary

The PDS series regulated DC power supplies offer versatile control over voltage and current. Key operations include:

  • Powering On/Off: Use the POWER switch. The unit can be configured for automatic ON setting.
  • Voltage and Current Adjustment: Utilize the VOLTAGE and CURRENT keys in conjunction with the rotary encoder.
  • Output Control: The OUTPUT key controls the output, with options for automatic ON setting.
  • Preset Memory: Store and recall up to three voltage and current settings using the MEM key and PRESET 1-3 keys.
  • Protection Features: Includes Over-Voltage Protection (OVP), Over-Current Protection (OCP), and Overheat Protection (OHP) to safeguard the unit and connected loads.
  • Remote Sensing: Compensates for voltage drops on the output lines.
  • Key Lock: The KEY LOCK (LOCAL) key locks most controls, preventing accidental changes.

Troubleshooting and error codes

Model Setting[V] Range[mV]
PDS20-18 20.500 ±1
PDS36-10 36.900 ±1
PDS60-6 61.500 ±1
