Brand: KENWOOD
Category: Refrigerator
Document Type: Manual
Language: EN
Manual for K4D556X18
Uploaded: Nov. 21, 2025, 8:47 p.m.
Warranty Information
Warranty information not explicitly stated in this document.
Operation
Plug the unit into the mains socket. The internal temperature is controlled by an electronic panel on the door. Before changing any setting, ensure the lock is disabled by pressing the Unlock button for 3 seconds.
Temperature Setting
- Fridge: 2°C to 8°C. Press Fridge button repeatedly. Setting to "OF" turns off the compartment.
- My Fresh Choice: 5°C to -20°C. Press My Fresh Choice button repeatedly. Setting to "OF" turns off the compartment.
- Freezer: -15°C to -25°C. Press Freezer button repeatedly.
Wait for selected temperature to flash for 10 seconds until steady to confirm.
Special Modes
- Super Freeze: Press Mode button. Freezer temperature quickly lowers to -25°C. Resumes previous setting automatically or when any button (except Unlock) is pressed.
- Holiday Mode: For periods of absence. Fridge sets to 15°C, Freezer to -18°C. Do not store food in the fridge.
- Smart Mode: Keeps food fresh. Fridge sets to 5°C, Freezer to -18°C.
Alarms & Locks
- Door Alarm: Activates if a door is open for over 2 minutes. Stops after 10 minutes. Close door to deactivate.
- Child Lock: Press Unlock for 3 seconds to activate (lock icon illuminates). Press Unlock for 3 seconds to deactivate (lock icon extinguishes). All buttons (except Unlock) are disabled when locked.
Noises:
Some unusual noises are normal due to refrigerant circulation.
Troubleshooting and error codes
| Problem | Possible Cause | Solution |
|---|---|---|
| The unit does not operate. | The unit is not plugged in. | Check the power plug is fully inserted into the mains socket. |
| The unit is not operating. | Power failure or the mains switch is off. | Check the power supply. |
| The internal temperature is too high. | The doors are opened too frequently. | Avoid opening the doors frequently. |
| The internal temperature is too high. | The doors are not closed properly. | Check the door seals are not obstructed and the doors are closed properly. |
| The internal temperature is too high. | The unit is not set to the correct temperature. | Adjust the temperature setting. |
| The internal temperature is too high. | Insufficient ventilation. | Ensure the ventilation openings are not obstructed. |
| The internal temperature is too high. | The unit is placed too close to a heat source. | Move the unit away from heat sources. |
| The compressor is running continuously. | The ambient temperature is high. | The appliance will run for longer in higher ambient temperatures. |
| The compressor is running continuously. | A large amount of food has been added to the unit. | Wait for the unit to return to the normal operating temperature. |
| The compressor is running continuously. | The doors have been opened frequently. | Avoid opening the doors frequently. |
| Condensation appears on the outside of the unit. | The unit is not designed to operate in a high humidity environment. | Wipe off any moisture residue. If the problem continues, please contact a qualified technician. |
| Food is not cold enough. | The temperature is set too high. | Adjust the temperature to a lower setting. |
| Food is not cold enough. | The doors are opened too frequently. | Avoid opening the doors too frequently. |
| Food is not cold enough. | The door seals are not airtight. | Check and clean the door seals. |
| Food is not cold enough. | The unit is overfilled. | Remove some food to allow air circulation. |
| Water dispenser is not working. | The water tank is empty. | Fill the water tank. |
| Water dispenser is not working. | The lock device is in the "Lock" position. | Ensure the lock device is in the "Unlock" position. |
| Water dispenser is not working. | The lever is not pushed correctly. | Push the lever correctly. |
| Water dispenser is not working. | The water tank valve is not inserted correctly. | Ensure the water tank valve is inserted correctly. |
