Manual for KSBS DIT18
Uploaded: Nov. 21, 2025, 6:18 p.m.
Warranty Information
None
Control Panel Overview
The electronic control panel on the door manages the unit's temperature. Ensure the child lock is disabled before making adjustments.
Temperature Settings
- Fridge: Range 2°C to 8°C. Press the 'Fridge' button repeatedly to set.
- Freezer: Range -14°C to -24°C. Press the 'Freezer' button repeatedly to set.
Special Modes
- Super Cool: Press and hold 'Super Cool' for 3 seconds. Fridge temperature drops to 2°C for 3 hours.
- Super Freeze: Press and hold 'Super Freeze' for 3 seconds. Freezer temperature drops to -24°C for 26 hours.
- Holiday Mode: Activates for extended periods away. Ice maker turns off automatically. Do not store food in the fridge.
- Eco Mode: Press 'Eco' button. Fridge sets to 8°C, Freezer to -15°C to save energy.
Other Functions
- Door Alarm: Sounds if a door is left open for over 2 minutes.
- Child Lock: Press and hold 'Child Lock' for 3 seconds to activate/deactivate.
- Ice/Water Dispenser: Press 'Cubed', 'Crushed', or 'Water' buttons. Flush lines before first use and discard first day's ice.
- Ice Maker On/Off: Press 'Ice Off' button. An icon will illuminate when off.
Tips
- Store food properly for optimal cooling and air circulation.
- Limit door openings to prevent cold air escape.
- Freeze food in small, appropriate portions.
- Always cool pre-cooked food before storing.
Troubleshooting and error codes
| Problem | Possible Cause | Solution |
|---|---|---|
| Unit does not operate | Unit is not plugged in. | Plug in the unit. |
| Unit is not switching on | Power cut or fuse blown. | Check the power supply and fuse. |
| Interior light does not work | LED panel failure. | Contact a qualified service agent. |
| Compressor runs continuously | The ambient temperature is too high. | Ensure the unit is in a suitable environment (10°C - 43°C). |
| Too much or too little cooling | Temperature is not set correctly. | Adjust the temperature settings. |
| Unit is noisy | Normal operational noises. | Refer to the 'Noises inside the unit!' section. |
| Door alarm sounds | Door is open for more than 2 minutes. | Close the door or press the 'Alarm' button. |
| Ice/Water dispenser not working | Ice maker is turned off. | Turn the ice maker on. |
| Water leaks from dispenser | Ice bucket not installed correctly. | Re-install the ice bucket. |
| Condensation on the unit | Change in room temperature. | Wipe off moisture. If persistent, contact a technician. |
