Manual for KUDI01IL

Manual for KUDI01IL

Brand: KitchenAid

Category: Dishwasher

Document Type: Manual

Language: EN

Uploaded: Nov. 21, 2025, 6:07 p.m.

Manual Publish Date: 2002-06-01

Warranty Information

One-year full warranty on parts and labor, with limited and lifetime warranties on specific components.

Using Your New Dishwasher

  1. Scrape food soil and hard items from dishes.
  2. Load dishwasher, ensuring spray arms can spin freely.
  3. Add detergent and check rinse aid dispenser.
  4. Close door firmly. Run hot water at sink until hot, then turn off.
  5. Select cycle and options, then press START.

Dishwasher Loading

  • Remove leftover food; rinsing is not necessary.
  • Load items so water spray reaches all surfaces and they don't overlap.
  • Load heavy items carefully.
  • Ensure lids, handles, etc., don't interfere with spray arms.
  • For quiet operation, secure lightweight items and prevent items from touching.

Detergent Dispenser

  • Dispenser has Pre-Wash and Main Wash sections.
  • Use automatic dishwashing detergent only.
  • Add detergent just before starting cycle.
  • Amount depends on water hardness and soil level.

Rinse Aid Dispenser

  • Rinse aid prevents spots and improves drying.
  • Fill dispenser as needed; lasts about 3 months.
  • Adjust setting for water conditions.

Dishwasher Efficiency Tips

  • Use hot water (120°F/49°C).
  • Do not pre-rinse dishes.
  • Use Normal cycle for less energy use.
  • Consider delay start or running at night.
  • Use air dry or energy-saving dry options.
  • Run full loads.

Cycle Selection

  • Select cycle and options, then press START.
  • Heavy: For heavily-soiled items and hard water.
  • Normal: For normally soiled loads.
  • Rinse Only: For rinsing dishes not to be washed immediately.

Options

  • Hi-Temp Scrub: Raises water temp, adds rinse for tough soils.
  • ENERGY SAVER™ Dry System: Dries without heat, saves energy.
  • Control Lock: Prevents unintended use.

Troubleshooting

  • Check door latch, power, water shut-off, and float for operational issues.
  • Ensure water is hot and cycles are complete for filling/drainage problems.
  • For cleaning issues, check loading, water temp, detergent, and spray arms.
  • Use rinse aid for spots and film.

Assistance/Service

  • Consult Troubleshooting first.
  • Call provided numbers for assistance or service.
  • Have model and serial number ready.

Warranty

  • One-Year Full Warranty on parts and labor.
  • Limited warranty on specific components (racks, motor, etc.).
  • Lifetime warranty on stainless steel tub/inner door against rust-through leaks.
  • Specific exclusions apply (installation, misuse, etc.).

Troubleshooting and error codes

Problem Possible Cause Solution
Dishwasher is not operating properly Door not closed tightly and latched Close and latch door securely.
Incorrect cycle selected Refer to "Cycle Selection Charts."
No power (fuse blown/breaker tripped) Check household fuse or circuit breaker.
Motor overload Motor will reset automatically within a few minutes. If not, call for service.
Water shut-off valve closed Turn water shut-off valve on.
Dishwasher will not fill Overfill protection float stuck Press float down to release. Ensure it moves freely.
Water supply issue Ensure water supply is adequate.
Dishwasher seems to run too long Water heating required Dishwasher heats water for optimal cleaning. Refer to "Dishwasher Efficiency Tips."
Water remains in the dishwasher Cycle not complete Ensure the cycle is finished.
Detergent remains in the covered section of the dispenser Cycle not complete Ensure the cycle is finished.
Lump-free detergent required Replace detergent if lumpy.
White residue on the front of the access panel Too much detergent used Refer to "Detergent Dispenser."
Odor in the dishwasher Infrequent use Run a rinse cycle daily until a full load is ready.
New plastic smell New plastic smell Run a vinegar rinse as described in "Troubleshooting."
Condensation on the kitchen counter (built-in models) Dishwasher not aligned with countertop Refer to Installation Instructions.
Dishes are not completely clean Incorrect loading Refer to "Dishwasher Loading."
Water temperature too low Ensure water is 120°F (49°C). Refer to "Dishwasher Efficiency Tips."
Incorrect amount or type of detergent Use recommended detergent, correct amount, and ensure it's fresh.
Detergent caked in dispenser Use fresh detergent. Clean dispenser.
Clogged pump or spray arm Check for labels from bottles/cans.
Low home water pressure Ensure pressure is 20-120 psi (138-828 kPa). Consider a booster pump.
High suds Never use soap or laundry detergents. Use recommended dishwasher detergents.
Spots and stains on dishes Hard water / high mineral content Use liquid rinse aid. Keep dispenser filled.
Water temperature too low Ensure water is 120°F (49°C).
Incorrect amount or type of detergent Use recommended detergent, correct amount, and ensure it's fresh.
Low home water pressure Ensure pressure is 20-120 psi (138-828 kPa).
White spots on cookware with non-stick finish Detergent removed seasoning Reseason cookware.
Brown stains on dishes and dishwasher interior High iron content in water Rewash with citric acid crystals (no detergent), then run Normal cycle with detergent. Consider an iron removal unit if frequent.
Black or gray marks on dishes Aluminum items rubbing Hand wash aluminum items. Remove marks with mild abrasive cleaner.
Orange stains on plastic dishes or dishwasher interior Tomato-based foods Stains fade over time. Heated drying slows fading. Regular rinse and air/energy-saving dry options reduce likelihood.
Dishes do not dry completely Improper loading / Overloading Refer to "Dishwasher Loading." Use liquid rinse aid.
Plastics wet Plastics often need towel drying.
Rinse aid dispenser empty Refer to "Rinse Aid Dispenser." Use heated drying if needed.
Chipping of dishes Improper loading Load dishes stably, avoid striking. Move racks slowly.
Delicate items Wash antiques, feather-edged crystal, etc., by hand.
Grinding, grating, crunching or buzzing sounds Hard object in wash module Object will be ground up. If sound persists, stop cycle.
