Manual for KGCS160
Uploaded: Nov. 21, 2025, 8:53 p.m.
Warranty Information
One-year full warranty for parts and labor, followed by a four-year limited warranty on burners.
TO OPERATE
Grasp the control knob, push down and turn to the left to "LIGHT." Gas flowing into the burner will be ignited by the electric spark ignitor and you will hear a clicking sound, indicating that the ignitors are functioning. Gas is flowing as long as knob is not in "OFF" position.NOTE: All four burner ignitors will spark regardless of which burner is being operated.
When the burner is lit, turn the control knob to the right to the desired flame setting, see guide below. The control knobs do not have fixed positions between "HI" and "LO." They can be turned to any of the settings indicated, or to any position in between. The ignitor will turn off and the clicking will stop when the control knob is turned from the "LIGHT" position to another setting.
CONTROL SETTING GUIDE
HI To start foods cooking and to bring foods to boiling.MED To continue frying after starting on "HI." For foods cooked in a double boiler.
LO To keep smaller amounts of food at the boiling point or for gently simmering foods; melting butter, chocolate and other heat-sensitive foods.
Troubleshooting and error codes
| IF YOU NEED SERVICE OR ASSISTANCE | |
| 1. If your cooktop should fail to operate, review the following list before calling your dealer. You could save the cost of a service call. | |
| • Has a house fuse blown, or is the circuit breaker open? | |
| • Is electric cord plugged into receptacle? | |
| • Is manual gas shut-off valve open? | |
| • Are burner ports plugged? | |
| • Are grates positioned so that locating pin is in hole in cooktop? | |
| • Are ignitor wires firmly attached to ignitor on each burner? | |
| 2. If the problem is not due to one of the above items, first call your dealer or repair service he recommends. | |
| • All service should be handled locally by the dealer from whom you purchased the unit or an authorized KitchenAid servicer. | |
| 3. In the event you are unable to obtain the name of a local authorized KitchenAid servicer, call KitchenAid Consumer Affairs, TOLL FREE: 800-422-1230. | |
| • A Consumer Affairs representative can recommend a qualified service company in your area. | |
| If you must call or write, please provide: Model Number, Serial Number, Date of Purchase and a complete description of the problem. Write to: | |
| KitchenAid Consumer Affairs KitchenAid, Inc. P.O. Box 558 St. Joseph, Michigan 49085-0558 | |
| 4. If you are not satisfied with the action taken, contact the Major Appliance Consumer Action Panel (MACAP). MACAP is a group of independent consumer experts that voices consumer views at the highest levels of the major appliance industry. Contact them only when the dealer, authorized servicer, or KitchenAid, Inc., have failed to resolve your problem. | |
| Major Appliance Consumer Action Panel 20 North Wacker Drive Chicago, IL 60606 | |
| MACAP will in turn inform us of your action. | |
