Warranty Information

LG offers a 1-year labor/parts warranty, a 2-year warranty on main control board, racks, and tub, and a 10-year warranty on the Direct Drive Motor.

Quick Start Guide:

  1. Load dishes, ensuring only dishwasher-safe items are used, food debris is scraped off, and items are not blocking spray arms or the detergent dispenser.
  2. Add the recommended amount of detergent, filling the prewash recess if desired.
  3. Turn on the dishwasher by pressing the Power button.
  4. Check rinse aid level; refill if the indicator light is on.
  5. Select the desired cycle and options based on the load.
  6. Operate the dishwasher by pressing the Start button and closing the door within four seconds, or closing the door first and then pressing Start.
  7. The cycle ends with a chime and an "End" display.

Troubleshooting and error codes

Problem Possible Cause & Solution
Spots and filming on dishes. Hard water buildup in the tub. Remove all dishes, silverware and silverware holder from dishwasher. Only racks should remain in tub. For best results, use citric acid powder (can be found in canning sections of most grocery stores or online). Measure 3 tablespoons (40 g) of citric acid powder. Fill main wash compartment with measured powder. If you cannot find citric acid powder, pour approximately one cup (200 ml - 300 ml) of white vinegar into shallow bowl and place in upper rack. Run Machine Clean (Download Cycle: P1) cycle. Do not use detergent.
Dishes don't dry. Rinse aid dispenser empty. Check and refill the rinse aid dispenser if empty.
Wi-Fi
Trouble connecting appliance and smartphone to Wi-Fi network The password for the Wi-Fi network was entered incorrectly. Delete your home Wi-Fi network and begin the connection process again.
Mobile data for your smartphone is turned on. Turn off the Mobile data on your smartphone before connecting the appliance.
The wireless network name (SSID) is set incorrectly. The wireless network name (SSID) should be a combination of English letters and numbers. (Do not use special characters.)
The router frequency is not 2.4 GHz. Only a 2.4 GHz router frequency is supported. Set the wireless router to 2.4 GHz and connect the appliance to the wireless router. To check the router frequency, check with your Internet service provider or the router manufacturer.
The appliance and the router are too far apart. If the appliance is too far from the router, the signal may be weak and the connection may not be configured correctly. Move the router closer to the appliance or purchase and install a Wi-Fi repeater.
During Wi-Fi setup, the app is requesting a password to connect to the product (on certain phones). Locate the network name which starts with "LG" under Settings > Networks. Note the last part of the network name. If the network name looks like LGE_Appliance_XX-XX-XX, enter Ige12345. If the network name looks like LGE_Appliance_XXXX, enter XXXX twice as your password. For example, if the network name appears as LGE_Appliance_8b92, then you would enter 8b928b92 as your password. In this instance, the password is case sensitive and the last 4 characters are unique to your appliance.
Installation Check Error Codes
IE Water supply line is kinked under dishwasher. Feed the drain and water supply hoses through the hole under the sink. Then gradually slide the dishwasher into the cabinet while pulling on the hoses under the sink to take up any slack. This helps avoid kinking the hoses or trapping them beneath the dishwasher. House water supply is not turned on. Turn the water faucet on.
DE Drain hose is kinked or pinched. Feed the drain and water supply hoses through the hole under the sink. Then gradually slide the dishwasher into the cabinet while pulling on the hoses under the sink to take up any slack. This helps avoid kinking the hoses or trapping them beneath the dishwasher. Drain hose is connected to the disposal without removing the knockout plug. Remove the knockout plug from the disposal. Waste tee or disposal is clogged. Remove knockout plug on the waste tee or disposal.
