Brand:
LG
Category: Dishwasher
Document Type: Manual
Language: EN
Manual for LUDP8997SN
Uploaded: Nov. 21, 2025, 6:54 p.m.
Manual Publish Date: 2017-01-01
Warranty Information
None
Refer to the "Features and Operation" section for details on QuadWash™ System, Inverter Direct Drive Motor, EasyRack Plus, Hybrid Drying System, and Smart ThinQ™. The "Control Panel" section describes the function of each button and display element, including Power, Display (Rinse Aid Icon, Digital Display), Control Lock, Wi-Fi, Cancel, and Start. Information on various Cycles (Auto, Heavy, Delicate, Refresh, Normal, Turbo, Express, Download Cycle, Machine Clean, Rinse) and Options (Dual Zone, Half Load, Energy Saver, Pre-Steam, High Temp, Extra Dry, Night Dry, Delay Start) is also provided.
Troubleshooting and error codes
| BUTTON | Times button is pushed | Top Display | Load and Checking points | Door open/ closed | Remark | ||
| Load | LED lighting | ||||||
| Start | 1 TIME | n35/U00/ D00 (Version) | All LEDs are lit | Either | "nC" will be displayed when NFC or Wifi Module fails. | ||
|---|---|---|---|---|---|---|---|
| 1 TIME | Sump Temp(°C) | Dispenser | Closed | "EE" will be displayed when EEPROM is fails. | |||
| 2 TIME | N02 | Drying Fan Motor Drying Actuator | Closed | ||||
| 3 TIME | Soil Level | Soil Sensor | |||||
| 4 TIME | Drain Motor RPM | Drain Motor | |||||
| 5 TIME | Frequency | Inlet Valve | |||||
| 6 TIME | Washing Motor RPM | Washing Motor | |||||
| 7 TIME | Washing Position | Washing Heater Vario Valve | |||||
| POWER +START | 8 TIME | - | Power Off | Either | All LEDs are turned Off | ||
