Brand:
LG
Category: Home Appliance
Document Type: Manual
Language: EN
Manual for LRE30757ST
Uploaded: Nov. 21, 2025, 9:18 p.m.
Manual Publish Date: 2008-01-01
- Surface Cooking Units: Control operation of individual elements, including single and dual surface units, and warming zones. Adjust power levels and check for hot surfaces.
- Oven Operation: Use controls for Bake, Broil, Convection Bake, and Convection Roast modes. Preheating is recommended for most modes. Oven light can be turned on/off manually.
- Timer & Clock: Set the clock time, use the timer for countdowns, and set cook times for automatic shut-off.
- Special Functions: Access options like convection auto conversion, thermostat adjustment, language selection, preheating alarm, beeper volume, and temperature unit settings. Other functions include Favorites, Cook & Warm, Oven Lockout, Proof, and Self-Clean.
- Warming Drawer: Operate the warming drawer to keep food warm, with adjustable heat settings and an automatic shut-off feature.
Troubleshooting and error codes
| PROBLEMS | POSSIBLE CAUSES & FAULTS | SOLUTIONS |
|---|---|---|
| Oven door sagging on one side | • Hinge loose or out of position to oven liner | • Adjust hinges or replace hinges |
| Door does not close completely at top | • Broken or misadjusted door spring • Door fits too tight at bottom. |
• Adjust or replace hinges • Adjust hinges outward. |
| Door glass breaks. | • Oven racks covered with foil. • Glass installed backward. |
• Do not cover racks with foil. • Install tempered glass toward the heat. |
| Damaged oven door gasket. | • Improper Self clean | • Do not use harsh abrasives or scouring pads. See Owner's manual intructions |
| Oven racks fit too tight. | • Racks were cleaned in self clean cycle • Tolerance buildup in oven liner. |
• Apply a small amount of vegetable oil to a paper towel and wipe the edges of the oven racks with the paper towel. Do not spray with pam or other lubricant sprays. • Notify customer Assurance department. |
| Oven smokes/odor first few times of usage | • This is normal | • Minor smoking or odor is normal for the first few tikes of oven usage • Ventilate area well and perform self clean cycle |
| Excessive smoking during a Self clean cycle | • Excessive soil | • Press the CLEAR/OFF pad. Open the windows to rid the room of smoke. Wait until the Self Clean cycle is cancelled Wife up the excess soil and reset the clean |
| Convection fan make a noise | • A convection fan may automatically turn on and off. Low level noise is normal • Loose nut of convection fan • Deformed convection fan |
• Low level noise is normal • Re-fasten the nut • Replace the convection fan. |
| Failures Codes | • Electronically controlled | • Refer to "Failure codes” parts (page 7-0~7-10) |
| Oven temperature too hot or too cold | • Oven sensor needs to be adjusted | • See "the adjusting your oven temperature" in owners manual |
