Brand: mabe
Category: Laundry Center
Document Type: Manual
Language: EN
Manual for MCL2040PSBB
Uploaded: Aug. 18, 2025, 10:56 p.m.
Manual Publish Date: null
Warranty Information
Read and follow this safety information carefully. Keep these instructions.
Washer
1. Program Selection: Turn the knob to select the desired program based on the type of clothes to wash.
2. Temperatures: Select from 5 water temperature levels or let the automatic sensor decide.
3a. Load Size: Choose from 4 load levels or the automatic sensor.
3b. Water Level: Choose from 4 water levels or the automatic sensor.
4. Function Selection: Press the button to select independent wash cycle functions.
5. Start/Pause: Press to start or pause operation.
Dryer
1a. Automatic Drying Cycles: Select temperature based on fabric type (High, Optimum, Low).
1b. Drying Cycles by Fabric Type: Choose Normal, Heavy/Sanitize, Delicate based on the load.
2. Start: Close the door and press Start.
Troubleshooting and error codes
| What to Do | Possible Cause | In the Washer |
| Excessive Suds | Too much detergent. Use less detergent, especially if the water is soft, the load is small, or not very dirty. | Excessive Suds |
| Washer Not Draining or Running | Cycle not finished. Wait for the cycle to complete. | Incomplete Cycle |
| Washer Vibrates or Moves | Load is unbalanced or washer is not level. Stop the washer and redistribute the load evenly. Ensure the washer is level. | Unbalanced Load / Unlevel Washer |
| Washer Does Not Start | Lid is open or power cord is not plugged in. Close the lid or plug in the power cord. | Open Lid / No Power Connection |
| Washer Not Filling with Water | Water supply is turned off or hoses are kinked. Turn on the water supply and straighten the hoses. | Water Supply Off / Kinked Hoses |
| Washer Makes Strange Noises | Metal or hard objects in the load. Remove objects before washing. | Foreign Objects in Load |
| Clothes Not Washing Properly | Too little or too much detergent was used. Ensure you are using the correct amount of detergent. | Incorrect Detergent Use |
| Washer Not Spinning | Spin cycle was not selected or the load is unbalanced. Select the spin cycle or redistribute the load. | Spin Cycle Not Selected / Unbalanced Load |
| Water Leak | Inlet or outlet hoses are not properly connected or are damaged. Check hose connections and condition. | Hose Leaks |
| Clothes Come Out Stained | Fabric softener or bleach was poured directly on clothes. Pour these products into the corresponding dispenser. | Stains from Softener or Bleach |
| Washer Won't Stop | Possible timer or electronic control malfunction. Call for service. | Timer or Electronic Control Malfunction |
